Lindy 73435 Manual
Read below 📖 the manual in Italian for Lindy 73435 (20 pages) in the Charger for mobile device category. This guide has been helpful for 6 people and has been rated 4.5 stars on average by 2 users
Page 1/20
© LINDY Group - FIRST EDITION
(April 2023)
120W 10 Port USB Charging Station
User Manual English
Benutzerhandbuch Deutsch
Manuel Utilisateur Français
Manuale Italiano
Manual de Usuario Español
No. 73435
lindy.com
User Manual English
Safety Instructions
! WARNING !
Please read the following safety information carefully and always keep this document with
the product.
Failure to follow these precautions can result in serious injuries or death from electric
shock, fire or damage to the product.
Touching the internal components or a damaged cable may cause electric shock, which
may result in death.
This device is a switching type power supply and can work with supply voltages in the range 100 - 240
VAC. For worldwide usability four different AC adapters are enclosed: Euro (Schuko) type, UK type,
US/Japan type and Australia/New Zealand type. Use the appropriate AC adapter and ensure it is firmly
secured in place and does not detach by pulling before installing into a power socket.
To reduce risk of fire, electric shocks or damage:

Do not open the product nor its power supply. There are no user serviceable parts inside.

Only qualified servicing personnel may carry out any repairs or maintenance.

Never use damaged cables.

Do not expose the product to water or places of moisture.

Do not use this product outdoors it is intended for indoor use only.

Do not place the product near direct heat sources. Always place it in a well-ventilated place.

Do not place heavy items on the product or the cables.

Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket
User Manual English
Introduction
Thank you for purchasing the 120W 10 Port USB Charging Station. This product has been designed to
provide trouble free, reliable operation. It benefits from both a LINDY 2 year warranty and free lifetime
technical support. To ensure correct use, please read this manual carefully and retain it for future
reference.
The Lindy 120W 10 Port USB Charging Station allows charging up to 8 USB Type A and 2 Type C devices
like tablets or smartphones. Each USB Type A port can provide up to 5V 2.4A, each USB Type C port can
provide up to 5V 3A to satisfy the most power hungry devices. If all 10 ports are occupied and/or when
total power draw is higher than 120W, load balancing will occur. With its smart charging function and
support of many different protocols like QC 3.0 (only type C ports), Samsung AFC and Apple 5V 2.4A
Charging Protocol and BC 1.2 (only Type A ports) this USB Charging Station can recognise the connected
device to automatically adjust the charging current for a fast and safe charge while also providing
overcurrent, overvoltage and short-circuit protection to avoid excessive current damaging the device.
Plastic dividers can be assembled and stood on the top of the unit, which allows different widths for
different tablets or mobile phone sizes. This product is perfect for use in schools, libraries, hotels,
restaurants or any location that uses multiple devices. Country specfic power cables are provided for
seamless use of the charging station, ideal for global events or integration into installations abroad.
Package Contents

USB Charging Station

11 plastic separators

20V 6A PSU with 5.5/2.5mm DC cable, 0.9m (2.95ft)

4 country specific power cables (Schuko/US/UK/AUS to IEC C5), 0.9m (2.95ft)

LINDY Manual
Features

Simultaneous charging of up to 10 tablets, smartphones and other USB Type A and Type C devices

Max. 5V 2.4A charging per USB Type A port, max. 5V 3A charging per USB Type C port

Smart charging function adjusts the current for optimum, safe charging

Battery Charging Standard 1.2 supports fast charging, Apple Charging Protocol, QC 3.0 and Samsung
AFC supported
Specification
 Interface: 8x USB Type A (Female), 2x USB Type C (Female)
 Compatibility: 8x USB Type A ports and 2x USB Type C ports for USB Type A and C devices
 Power Requirements: 20V 6A
 Output Power: 5V 21A
 Power Delivery: -
 Special Features: Battery Charging 1.2 (USB Type A ports); Smart Charging; QC 3.0 (USB Type C
ports); Samsung AFC; Apple 5V 2.4A Charging Protocol; Overcurrent, overvoltage and short-circuit
protection, LED indicator (lights up in green when power is on)
 Dimensions (approx.) WxDxH: 238x118x26mm (9.37x4.65x1.02in)
 Housing Material: Plastic
 Net Weight: 0.98kg (2.16lb)
 Operating Temperature: 5°C - 35°C (41°F - 95°F)
Product Specifications
| Brand: | Lindy |
| Category: | Charger for mobile device |
| Model: | 73435 |
