Page 1/10
Part no.:
| DESCRIPTION
43365
60m USB 1.1 Cat.6 Extender
60m USB 1.1 Extension
Extends a single USB port up to 60m using low cost Cat.5e/6 network cable (not included)
Supports data transfer rates of up to 12Mbps
Plug and Play Installation, OS independant
Powered by the USB Bus
2 year warranty
The Lindy Cat.6 USB Extender can be used to extend the distance between a USB device and a host computer by up to 60m. It
consists of a local unit, which can be connected to the computer or laptop and a remote unit which connects to USB devices like
mice or keyboards, perfect for long distance access.
Standard, low cost Cat.5e/6 cable (not included) is used to connect the two units together. For best performance and compatibility,
we recommend the use of solid core patched cables.
•
•
•
•
•
Speci cationsfi
USB Standard: USB 1.1
Supported Bandwidth: 12Mbps
Maximum Distance: 60m (196ft)
Transmission Medium: Cat5e/6 (or higher) network cable
Chipset: BCH4105G
Special Features: -
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Connectors
Transmitter Input: USB Type A male
Transmitter Output: RJ45 female
Receiver Input: RJ45 female
Receiver Output: USB Type A female
Power: -
Physical Properties
Dimensions WxDxH:
Transmitter: 53x26x20mm (2.09x1.02x0.79in)
Receiver: 53x26x20mm (2.09x1.02x0.79in)
Housing Material: Plastic
Net Weight: 0.54kg (0.12lb) (both units)
Operating Temperature: 0°C - 70°C (32°F - 158°F)
Storage Temperature: -20°C - 80°C (-4°F - 176°F)
Humidity: 0 - 90% RH (non-condensing)
Power Requirements: -
Colour: Black
Miscellaneous
Packaging Type: Carton Box
Packaging Dimensions: 180x105x30mm (7.09x4.13x1.18in)
Gross Weight: 0.113kg (0.25lb)
Warranty (Years): 2
Product Compliance: CE, FCC, RoHS & REACH, CP65
Package Content
Transmitter Unit
Receiver Unit
Lindy manual
Purchasing Information
No.: 43365
EAN: 4002888433655
•
•
•
•
•
•
◦
◦
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
| TECHNICAL DATA SHEET
Artikelnr.:
| BESCHREIBUNG
43365
60m USB 1.1 Cat.6 Extender
60m USB 1.1 Verlängerung
Überbrückt mit einem günstigen Cat. 5e/6-Netzwerkkabel (nicht enthalten) Distanzen bis 60m
Unterstützt Datentransferraten bis 12Mbit/s
Plug & Play, betriebssystemunabhängig
Stromversorgung über den USB Bus
2 Jahre Garantie, mehr über Garantiebedingungenhier
Dieser Lindy USB 1.1 Cat.6 Extender überbrückt Distanzen bis 60m zwischen einem USB-Gerät und dem Computer. Er besteht aus
einer lokalen Einheit, die mit dem Computer bzw. Laptop verbunden wird, und einer Empfangseinheit, an die USB-Geräte wie z.B.
Mäuse oder Tastaturen angeschlossen werden können.
Sende- und Empfangseinheit des Extenders werden mit einem Cat.5e/6-Netzwerkkabel (nicht enthalten) verbunden. Wir
empfehlen die Verwendung von Patchkabeln mit starren Adern, um die bestmögliche Performance und Kompatibilität zu
erreichen.
•
•
•
•
•
Spezi kationenfi
USB Standard: 1.1
Unterstützte Bandbreite: 12 Mbit/s
Max. Reichweite: 60m (196ft)
Übertragungsmedium: Cat.5e/6 (oder höher) Netzwerkkabel
Chipsatz: BCH4105G
•
•
•
•
•
| TECHNICAL DATA SHEET
