Page 1/22
Installation Guide
Quality, Design and Innovation
home.liebherr.com/fridge-manuals
Contents
1 General safety instructions.................................. 2
2 Setup conditions................................................... 3
2.1 Space............................................................................. 3
2.2 Setting up multiple appliances.................................. 3
2.3 Electrical connection................................................... 4
3 Appliance dimensions........................................... 4
4 Recess dimensions................................................ 5
4.1 Internal dimensions..................................................... 5
5 Ventilation requirements...................................... 5
6 Custom panel weights.......................................... 6
6.1 Weight............................................................................ 6
7 Water connection*................................................ 6
7.1 Dimensions for the water connection...................... 6
7.2 Water pressure............................................................. 6
8 Transporting the appliance................................... 6
9 Unpacking the appliance...................................... 7
10 Setting up the appliance....................................... 7
10.1 After setup.................................................................... 7
11 Disposal of packaging........................................... 7
12 Explanatory symbols used.................................... 7
13 **** freezer compartment door*.......................... 8
13.1 Moving the door hinge................................................ 8
14 Reversing the door................................................ 8
15 Connecting the appliance to the water supply*.. 10
15.1 Connecting the hose................................................... 11
15.2 Check the water system............................................. 11
16 Fit the appliance into the recess.......................... 11
17 Cabinet fronts....................................................... 18
17.1 Dimensions.................................................................... 18
17.2 Mounting the cabinet front(s).................................... 19
17.3 Setting the clearance to avoid collision................... 19
18 Water tank*........................................................... 19
18.1 Inserting the water tank............................................. 19
19 Water filter*.......................................................... 19
19.1 Installing the water filter............................................ 20
20 Connecting the appliance to the power supply.... 20
The manufacturer is constantly working to improve all types
and models. Therefore, please be aware that we reserve the
right to make changes to the shape, equipment and techâ
nology.
Symbol Explanation
Read instructions
Please read the information in these instrucâ
tions carefully to understand all of the benefits
of your new appliance.
Symbol Explanation
Full instructions on the internet
You can find detailed instructions on the
internet using the QR code on the front of
these instruction or by entering the service
number at home.liebherr.com/fridge-
manuals.
The service number can be found on the serial
tag:
Fig.îîExample illustration
Check appliance
Check all parts for transport damage. If you
have any complaints, please contact your
agent or customer service.
Differences
These instructions apply to a range of models,
so there may be differences. Sections that
apply to certain models only are indicated by
an asterisk (*).
Instructions and results
Instructions are marked with a .
Results are marked with a .
Videos
Videos about the appliances are available on
the YouTube channel of Liebherr-HausgerÀte.
1î General safety instructions
-Please keep this assembly manual in a safe
place so you can refer back to it at any
time.
-If you pass the appliance on, please hand
this assembly manual to the new owner.
-Read this assembly manual before installaâ
tion and use in order to use the appliance
safely and correctly. Follow the instrucâ
tions, safety instructions and warning
messages included at all times. They are
important for ensuring you can operate and
install the appliance safely and without any
problems.
-First read the general safety instructions in
the âGeneral safety instructionsâ section of
the operating instructions, which accomâ
pany these installation instructions, and
follow them. If you cannot find the operâ
ating instructions, you can download the
operating instructions from the internet by
entering the service number at
home.liebherr.com/fridge-manuals. The
General safety instructions
2 * Depending on model and options
service number can be found on the serial
tag:
-Observe the warning messages and other
detailed information in the other sections
when installing the appliance:
DANGER indicates a hazardous situation,
which if not avoided, will result in
death or serious injury.
WARNING indicates a hazardous situation,
which if not avoided, could result
in death or serious injury.
CAUTION indicates a hazardous situation,
which if not avoided, will result in
minor or moderate injury.
NOTICE indicates a hazardous situation,
which if not avoided, could result
in damage to property.
Noteî indicates useful advice and tips.
2î Setup conditions
WARNING
Risk of fire due to moisture!
If live parts or the power cord get wet, this can cause a
short circuit.
uThe appliance is designed for use in enclosed spaces. Do
not operate the appliance in open space or in damp areas
or where there is spray.
Normal use
-Only set up and use the appliance in enclosed spaces.
-Only use once installed.
2.1î Space
WARNING
Leaking refrigerant and oil!
Fire. The refrigerant contained within the appliance is enviâ
ronmentally friendly, but flammable. The oil contained
within the appliance is flammable. Escaping refrigerant and
oil can ignite if they are of high enough concentration and
are exposed to an external heat source.
uDo not damage the pipelines of the coolant circuit and
the compressor.
-If the appliance is installed in a very damp environment
condensate water may form on the outside of the appliâ
ance.
Always ensure sufficient airflow and ventilation in the
setup location.
-The more refrigerant there is in the appliance, the larger
the space that it is installed in must be. If the space is
too small, any leak may create a flammable mixture of
gas and air. For every 8 g of refrigerant, the installation
space must be at least 1îm3 . Specifications on the refrigâ
erant in the appliance can be found on the serial tag
plate inside the appliance.
2.1.1î Installation surface
-The floor of the installation site must be horizontal and
level.
-If you are installing the unit in a cabinet standing on an
uneven floor: level the cabinet.
2.1.2î Installation position
-Do not install appliance in direct sunlight or next to an
oven, radiator or similar.
-Only install the appliance in solid cabinets.
Note
A set for restricting the door opening angle to 90° can be
acquired from Customer Services for appliances with soft
closing.*
2.2î Setting up multiple appliances
NOTICE
Risk of damage caused by water condensate!
uDo not install this device directly beside another fridge/
freezer compartment.
NOTICE
Risk of damage caused by water condensate!
uDo not stack the appliance directly on top of another.
These appliances are designed for different types of instalâ
lation. Only combine appliances if the appliances are
designed for this. The following table shows the installation
options by model:
Setup type Model
Single All models
Side-by-Side
(SBS)
Model that start with .S...
Stacked Models up to a maximum recess height of
880 mm and with a heated cover can be
âstackedâ.
Upper appliance: up to a maximum recess
height of 140îmm
Fig.î1î
Install each appliance into its own recess.
Setup conditions
* Depending on model and options 3
