Page 1/24
Installation
Instructions
For Fully Integrated NoFrost
Combined Refrigerator-Freezers
HC 1580 / HC1581
7084 999-00
2
Important
Content Page
Please Read and Follow these Instructions .................. 2
Note to the Installer ........................................................ 2
Important Safety Information ......................................... 3
R600a Refrigerant.......................................................... 4
Disposal of Old Appliance ............................................. 4
Disposal of Packaging Material ..................................... 4
Electrical Safety ............................................................. 5
Blocking for Safety ......................................................... 5
Unit Dimensions ............................................................. 6
Door Swing Clearance ................................................... 6
Unit Venting .................................................................... 6
Cabinet Opening Dimensions ........................................ 7
Panel Dimensions - Inset Installation Style ................... 8
Panel Dimensions - Frameless Installation Style .......... 9
Mounting the Anti Tipping Device .................................10
Cover Strips ..................................................................11
Water Connection Requirements .................................12
Water Connection Adapter ...........................................12
Connection to the Water Supply ...................................13
Leveling the Appliance ..................................................14
Fastening the Appliance in the Recess ........................14
Adjusting the Refrigerator Door ....................................15
Adjusting the Drawer Front ...........................................15
Mounting the Ventilation Grille ......................................16
Before Mounting the Door Panels ................................17
Mounting the Attachment Brackets onto the Door
Panels ...........................................................................18
Mounting the Refrigerator Door Panel ..........................19
Mounting the Freezer Drawer Panels ...........................21
Please Read and Follow these
Instructions
These instructions contain Danger, Warning, and
Caution notes.
This information is important for safe and efficient instal-
lation and operation.
Always read and comply with all Danger, Warning, and
Caution notes!
DANGER!
Danger indicates a hazard which
will cause serious injury or death if
precautions are not followed.
WARNING!
Warning indicates a potentially hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION!
Caution indicates a potentially hazardous
situation which, if not avoided, may result
in minor or moderate injury.
IMPORTANT
This indicates information that is especially relevant
to a problem-free installation and operation.
Note to the Installer
It is very important to follow the instructions in the manu-
al to ensure proper installation and operation of the unit.
Before installing the unit, be sure to thoroughly read and
understand all of the information in this manual.
WARNING!
Electrocution hazard.
Do not connect to the electrical outlet
before the installation is completed.
IMPORTANT
All types and models are subject to continuous
improvement. The manufacturer reserves the right
to make modifications to the shape, equipment, and
technology.
3
Safety
Important Safety Information
• WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in struc-
ture, clear of obstruction.
• WARNING: Do not use mechanical devices
or other means to accelerate the defrosting
process, other than those recommended by
the manufacturer.
• WARNING: Do not damage the refrigerant
circuit.
• WARNING: The power cord must not be
damaged while installing the appliance.
• WARNING: Multi-sockets or distributor strips
and other electronic devices (such as halo-
gen transformers) must not be positioned
and operated at the rear of appliances.
• WARNING: Danger of injury through electric
shock! There are live parts under the cover.
Only have the interior LED light replaced or
repaired by customer service staff or trained
personnel.
• WARNING: Risk of injury from the LED lamp.
The light intensity of the LED light complies
with risk group RG 2. If the cover is defective,
do not look directly at the light through optical
lenses from close distance. This may dam-
age your eyes.
• WARNING: This appliance must be secured
as described in the Use and Care Manual
(Installation Instructions) to rule out any
potential risks due to its instability.
• WARNING: Do not use electrical appliances
inside the food storage compartments of the
appliance, unless they are of the type recom-
mended by the manufacturer.
• Any repairs and work on the appliance
should only be performed by the customer
service department. Unauthorized work may
be dangerous to the user. The power source
cable should only be changed or replaced
by the customer service department.
Component parts and power cords shall be
replaced with like components performed by
factory authorized service personnel only.
• Do not stand on the toe kick, drawers or
doors or use them to support anything else.
• This appliance is not intended for use by per-
sons (including children) with reduced physi-
cal, sensory or mental capabilities or lack of
experience and knowledge unless they have
been given initial supervision or instruction
concerning use of the appliance by a person
responsible for their safety. Children should
be supervised to ensure that they do not play
with the appliance.
• Do not store explosive substances such as
aerosol cans with a flammable propellant in
this appliance.
• To prevent injury and damage to property,
the appliance should only be installed by 4
people.
• Check the appliance for signs of damage
after unpacking. Contact the supplier if it is
damaged. Do not connect the appliance to
the mains power supply.
• Avoid prolonged skin contact with cold sur-
faces (e.g., chilled/frozen products). If neces-
sary, take safety action (e.g., gloves).
• Do not consume food which has been stored
for too long; it could cause food poisoning.
