LG VC23GA Manual

Read below 📖 the manual in Italian for LG VC23GA (44 pages) in the Not categorized category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users

Page 1/44
1
*MFL719826022302REV04*
1 2
www.lg.com
Copyright © 2023 LG Electronics Inc.
All Rights Reserved.
2
1
2
90°
3
3
ENGLISH
Model VC23GA
Size (width x height x thickness) 80 mm x 35.4 mm x 23.1 mm
(3.1 inches x 1.39 inches x 0.9 inches)
Weight 38 g (0.08 lb)
Video
Lens Focus 56 cm (22.0 inches) or more
Visual range 76.9° diagonally
Pixels 1920 x 1080, 30fps
Output format MJPEG, YUV2
Output image FHD, HD, VGA, QVGA
Audio MIC 2
Interface USB Type-C (USB2.0)
Power DC 5 V, max. 500 mA
Supported models Smart TV operating system of webOS22
or later
Environmental
conditions
Operating
temperature
(Humidity)
0 °C - 45 °C / 32 °F - 113 °F
(0 % - 80 %)
Storage temperature
(Humidity)
-10 °C - 65 °C / 14 °F - 149 °F
(0 % - 90 %)
Note
•You can download manuals, including those related to installation, use, troubleshooting,
specifications, licences, etc., from the LG Electronics website and view them on a PC
or mobile device.
•In the case of gallery models (OLED Z/G series), cables may pass between the wall and
the TV in the wall-mounted state.
•When installing the camera on a wall-mounted model, be careful not to lift the TV.
•When attaching the magnetic stand, remove dust and moisture before installation.
Reattachment of the magnet stand may cause bending or poor adhesion.
•Tapes may leave a mark (adhesive residues) after use due to the nature of the adhesive
product.
•Install the camera on the back of the TV where the magnet can be attached.
•When organizing cables, be careful not to block the ventilation holes of the TV.

Product Specifications

Brand: LG
Category: Not categorized
Model: VC23GA
