Page 1/12
NOTE COUNTER
KABNKNTCNTA
Connect the achine to the M P S ower upply
Connect the power cord to a wall outlet or power supply (AC 5220V ±10%, 0Hz). Note that
this device must be operated under the required voltage and frequency.
Prepare the D evice
• Ensure the device is set up on a secure, durable and level surface. Inclinations may lead
to counting errors.
• Set the position of the note guide to be 2mm- - to 3mm longer than the banknotes being
counted.
Verifying and A djusting the Hopper Plate
• The Hopper Plate ensures proper feeding of the banknotes for counting. It is secured to
the back of the device with two pivoting points and a magnetic lock.
• To verify that the hopper plate is properly adjusted, press or lift the hopper plate and look
for any displacement (see the figure). If any displacement occurs, press or lift the hopper
until the magnetic lock holds the piece in place.
• Adjust a proper gap between hopper and feeding roller by turning the adjustment screw
(Fig 1). Turn it left to decrease the space and turn right to increase it.
Fig 1
BEFORE FIRST USE
