Kicker CX800.1 Manual
Read below š the manual in Italian for Kicker CX800.1 (28 pages) in the Receiver category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/28
CX
AMPLIFIERS
Ownerās Manual
CXA400.1 | CXA800.1
CXA1200.1 | CXA1800.1
Manual del Propietario | EspaƱol
AMPLIFICADOR DEL LA SERIE CX.1
Benutzerhandbuch | Deutsch
MONOVERSTĆRKER DER CX.1-SERIE
Manuel dāutilisation | FranƧaise
AMPLIFICATEUR DE SĆRIE CX.1
2019 CXA Mono Amps Rev H.indd 1
2019 CXA Mono Amps Rev H.indd 1
2019 CXA Mono Amps Rev H.indd 1
2019 CXA Mono Amps Rev H.indd 1
2019 CXA Mono Amps Rev H.indd 1 10/7/2019 2:33:32 PM
10/7/2019 2:33:32 PM
10/7/2019 2:33:32 PM
10/7/2019 2:33:32 PM
10/7/2019 2:33:32 PM
2
CX.1-SERIES AMPLIFIERS
OWNERāS MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER ampliļ¬ er. Make sure there are no items
behind the area where the screws will be driven. Choose a location that allows at least 4ā (10cm) of open
ventilation for the ampliļ¬ er. If possible, mount the ampliļ¬ er in the climate-controlled passenger compartment. Drill
four holes using a 7/64ā (3mm) bit and use the supplied #8 screws to mount the ampliļ¬ er.
The KICKER CX Ampliļ¬ ers are capable of space-saving vertical mounting. Use a 2.5mm hex key (Allen wrench)
to loosen the end panel, remove the existing brackets, then insert and tighten the double-slotted brackets to the
ampliļ¬ er as illustrated on the next page.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
MODEL: CXA400.1 | CXA800.1
CXA1200.1 | CXA1800.1
Model: CXA400.1 CXA800.1 CXA1200.1 CXA1800.1
RMS Power [Watts]
@ 14.4V, 4ī mono, ā¤ 1% THD+N
@ 14.4V, 2ī mono, ā¤ 1% THD+N
@ 14.4V, 1ā¦ mono, ā¤ 1% THD+N
150W x 1
300W x 1
400W x 1
300W x 1
600W x 1
800W x 1
600W x 1
1200W x 1
1200W x 1
900W x 1
1800W x 1
1800W x 1
Length [in, cm] 8-1/8, 20.6 8-1/8, 20.6 12, 30.6 13-5/8, 34.6
Speciļ¬ cations common to all models:
Height [in, cm] 2-3/8, 5.9
Width [in, cm] 6-3/4, 17
Frequency Response [Hz] 25ā200
Signal-to-Noise Ratio [dB] >95, A-weighted, re: rated power
Input Sensitivity Low Level: 125mVā5V
High Level: 1Vā40V
Electronic Crossover Variable Lo-pass 50Hzā200Hz, 12dB/octave
KickEQā¢ Bass Boost Variable 0ā6dB @ 40Hz
Subsonic Filter 25Hz, 24dB/octave
Remote Bass Yes (sold separately)
WARNING: KICKER products are capable of producing sound levels that can permanently damage your hearing! Turning up a
system to a level that has audible distortion is more damaging to your ears than listening to an undistorted system at the same
volume level. The threshold of pain is always an indicator that the sound level is too loud and may permanently damage your
hearing. Please use common sense when controlling volume.
Pro Tip: To get the best performance from your new KICKER Ampliļ¬ er and extend the warranty by 1 year, use
genuine KICKER accessories and wiring.
NOTE: 2019 CXA mono ampliļ¬ ers are 1Ī© stable - power rating +/- 10%.
2019 CXA Mono Amps Rev H.indd 2
2019 CXA Mono Amps Rev H.indd 2
2019 CXA Mono Amps Rev H.indd 2
2019 CXA Mono Amps Rev H.indd 2
2019 CXA Mono Amps Rev H.indd 2 10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
3
Wiring: Disconnect the vehicleās battery to avoid an electrical short. Then, connect the ground wire to the
ampliļ¬ er. Make the ground wire short, 24ā (60cm) or less, and connect it to a paint-and-corrosion-free, solid,
metal area of the vehicleās chassis. Adding an additional ground wire of this same gauge (or larger) between the
batteryās negative post and the vehicle chassis is recommended.
The CX ampliļ¬ er has dual input sensitivity differential RCA inputs which will receive either high or low level signals
from your car stereoās source unit. A high-level signal can be run from the source unitās speaker outputs to the
stereo RCA input on the end panel of the ampliļ¬ er using the KICKER KISL as shown (make sure you set the CX
ampliļ¬ erās input level switch to āHIā). Alternatively, the signal can be delivered to the ampliļ¬ er using the low-level
RCA outputs on the source unit. Set the input level switch on the end panel of the ampliļ¬ er to āLOā. Either input
method will provide an output signal at the RCA output, which effectively passes the audio signal to another
ampliļ¬ er or component. Keep the audio signal cable away from factory wiring harnesses and other power wiring.
If you need to cross this wiring, cross it at a 90 degree angle.
source unit
high-level speaker
outputs
to ampliļ¬ er
shield
double-slotted
bracket
+
ā
core conductor
OR
VERTICAL MOUNTING
hex screws
ampliļ¬ er end panel
KICKER KISL (optional)
from source unit high-
level speaker outputs
to ampliļ¬ er
Install a fuse within 18ā (45cm) of the battery and in-line with the power cable connected to your ampliļ¬ er. If you
ever need to remove the ampliļ¬ er from the vehicle after it has been installed, the ground wire should be the last
wire disconnected from the ampliļ¬ er--just the opposite as when you installed it.
2019 CXA Mono Amps Rev H.indd 3
2019 CXA Mono Amps Rev H.indd 3
2019 CXA Mono Amps Rev H.indd 3
2019 CXA Mono Amps Rev H.indd 3
2019 CXA Mono Amps Rev H.indd 3 10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
10/7/2019 2:33:34 PM
