Page 1/8
P/N: 40-9538-05
model / 型号 IGS 1315SN
IGS 1315EN
IGS 1515
IGS 152
Infrared Gas Stove
/ / 红外线煤气炉
Dapur Gas Infra-Merah
Instruction Manual / Buku Panduan说明指示书 /
Please read this manual carefully before operating this product. Keep this manual handy for further reference.
请在使用此产品前,详读此说明书。并将之收藏以作日后参考。
Sila baca buku panduan ini dengan teliti sebelum menggunakan produk ini. Simpanlah untuk rujukan masa depan.
Important / Mustahak重要/
1
Parts identication / / 零件名称
Pengenalan bahagian
Model / / 型号 Model
Burner Size / / 燃烧器尺寸
Saiz Pembakar
Ignition System / / 点火系统
Sistem Nyalaan
Gas / / 气体 Gas
Rubber Hose Diameter /
/橡胶管直经
Diameter Salur Getah
Dimension / / 体积 Dimensi
:
:
:
:
:
:
IGS 1515 / IGS 152
150mm & 150mm
Piezo Type / Jenis Piezo
Liqueed Petroleum Gas (LPG)
液体煤气
Gas Cecair Petroleum
10mm
740 x 410 x 140mm
Enamel Wok
Stand 珐琅锅架
Tapak Kuali Enamel
Spill Tray 汤盘
Talam Tadahan
Ceramic mesh 陶瓷网罩
Jaring seramic
2 Chamber Burner Assembly 双管红外线燃烧器
2 Penunu Pembakar Infra-merah
(• For IGS1315 Left burner only 1 chamber and size is 130mm)
(• ) 对于IGS1315，左边的燃烧器只有一个隔间，尺寸是130mm
( untuk IGS1315 Pembakar Kiri hanya 1 ruang dan bersaiz 130mm)•
Ignition Knob 点燃钮
Tombol Nyalaan
Sparker Assembly 火花机
Penunu Percikan Api
LPG Inlet Pipe 煤气入口管
Salur Penyambung Gas ( LPG )
Specication / / 规格 Spesifikasi
*Specications are subject to change without prior notice / / 以上规格有何更改,恕无通知 Spesifikasi boleh ditukar tanpa sebarang notis
IGS 1315SN / IGS 1315EN
130mm & 150mm
Piezo Type / Jenis Piezo
Liqueed Petroleum Gas (LPG)
液体煤气
Gas Cecair Petroleum
10mm
740 x 410 x 140mm
2
4. Use good quality LPG hose provided FREE. Ensure it is properly connected to inlet pipe
and gas regulator. Make sure the hose does not pass over or come in contact with the
body of the appliance.
使用免费提供质量良好的煤气软管。确保煤气管紧紧连接着煤气调控掣和煤气炉的
入口管。确保煤 气管没有跃过煤气炉或与煤气炉任何部分接触。
5. Insert regulator onto outlet valve of LPG cylinder.
将煤气调控掣接去煤气桶。
6. Turn regulator control lever downwards to release LPG into appliance.
将煤气调控掣往下转以解放煤气。
7. After installation, test with soapy water for gas leaks.
安装后用肥皂水检查煤气外漏。
8. Do not use connecting hose that is longer than 2 metres.
2 m勿使用超过 长的煤气管。
9. Observe minimum clearance distance 150mm from the walls.
150mm 确保煤气炉与墙壁有至少 的距离。
2. This appliance should be installed by a qualied person to avoid hazards.
以防意外，此器具须由技术人员安装。
3. Connect hose to LPG inlet pipe.
Recommend to use new hose and new
hose clip (screw type).
将煤气管接至煤气入口管。建议使用
新的煤气管和煤气管锁。(螺旋型管锁）
Screw Hose Clip
OK 正确
NO 错误
NO 错误
Hose Clip Hose Clip
Installation Guide / 安装指南
To Gas
Regulator
煤气调控掣 煤气入口管 螺旋型管锁 普通管锁 普通管锁
LPG
inlet pipe
How to use / 使用方法
1. Turn on gas supply from LPG cylinder by turning the regulator control lever downwards.
确保煤气供应已接通。
2. Press ignitor knob and turn anti clockwise. Hold position for about 2-3 seconds until the burner is lighted.
将点燃钮按下，向左转。保持这姿态约二至三秒直到火已点燃整个燃烧器。
3. Air may be accumulated in the gas hose during installation. You may have to repeat above procedure several
times initially.
上述形势可能需重复数次，以确保煤气管里的空气已被排出。
Hose
接管
1. This Infrared Gas Stove must be connected to LPG cylinder with the FREE Triple Safety Gas Regulator provided.
Failing which will void all warranty.
此红外线煤气炉必须使用免费提供的三重安全燃气稳压器连接到液化煤气桶。否则将丧失所有保修。
