Karma BM 661USB2 Manual
Read below 📖 the manual in Italian for Karma BM 661USB2 (20 pages) in the Speaker category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/20
www.karmaitaliana.it
BM 661USB1
BM 661USB2
Professional procession system
Processioniere professionale
MANUALE DI ISTRUZIONI
Instruction Manual
2
• OTHER LANGUAGES •
• OTROS IDIOMAS •
• AUTRES LANGUES •
• OUTRAS LÍNGUAS •
PT
ES
FR
DE
INDICE / INDEX
CONTENUTO DELLA CONFEZIONE / PACKAGING CONTENT
COLONNA
Amplifier
2 TROMBE
2 x speakers
TREPPIEDE
Tripod stand
CINGHIA
Carrying strap
1/2 RADIOMICROFONI
1/2
wireless
microphones
MANUALE
Manual
• ITALIANO
• ENGLISH
PAG. 4
PAG. 12
ADATTATORE + CAVO
Power adaptor+ cable
All’apertura della confezione controllate che il prodotto sia integro e che siano presenti tutti i
componenti. Comunicate immediatamente al venditore eventuali danni o mancanze.
When you open the package check that product is in good condition and that all the parts are
present. Immediately notify the seller if any part is damaged or missing.
Faça a leitura deste código QR para
verificar a disponibilidade do manual na
sua língua
Escanea este código QR para
comprobar la disponibilidad del manual
en tu idioma
Scannez le code QR pour vérifier la
disponibilité du mode d’emploi
dans votre langue.
Scannen Sie den QR-Code, um
nach dem Handbuch in Ihrer
Sprache, wenn es verfügbar
is, zu suchen
3
Il fabbricante, allo scopo di migliorare i propri prodotti, si riserva il diritto di modificarne le
caratteristiche siano esse tecniche o estetiche, in qualsiasi momento e senza al cun preavviso.
The manufacturer, in order to improve its products, reserves the right to modify their
characteristics whether technical or aesthetic, at any time and without notice.
IT
EN
SPECIFICHE TECNICHE - TECHNICAL SPECIFICATIONS
Struttura
Alluminio
Potenza Max
50W
Autonomia
4 ore circa
Raggio operativo
radiomicrofoni
50 mt circa
Ingressi
1 Microfono, 1 AUX - USB/SD
Regolazioni
Toni alti / bassi / contrasto display
Alimentazione
Dati adattatore:
-Batteria ricaricabile: (14,4V - 3000 mAh NI-MH Cells)
-Rete: 230V ~ 50 Hz (tramite adattatore di rete)
-Batt. esterna 12V (interno positivo), 2A min.
Input 230V~ AC
Output 16V DC (per alimentazione processioniere)
Output 28V DC (per ricarica batteria)
Dimensioni
1250 x 65 x 45 mm
Peso
4 Kg circa
Alimentazione radiomicrofono
2 batterie stilo (AA)
Banda radiomicrofoni
UHF (multicanale) Freq 640,00 - 655,00 Mhz e/o 655.00-690.00 Mhz
Structure Aluminum
Max power 50W
Autonomy About 4 hours
Wireless microphone
operating range
About 50 meters
Inputs 1 Microphone, 1 AUX - USB / SD
Settings Bass / treble/ display contrast
Power supply
Adaptor
- Rechargeable battery (14.4V - 3000 mAh NI-MH Cells)
- Mains: 230V - 50 Hz (through power adaptor)
- 12V external battery (int. pole positive), 2A min.
Input 230V~ AC
Output 16V DC (for power supply)
Output 28V DC (battery recharge)
Dimensions 1250 x 65 x 45 mm
Weight About 4 kg
Wireless microphone power
supply
2 x AA batteries
Wireless microphone band
UHF (multich.) Freq 640,00- 655,00 Mhz and/or 655.00-690.00 Mhz
Product Specifications
| Brand: | Karma |
| Category: | Speaker |
| Model: | BM 661USB2 |
