JLab Epic Lab Edition Manual

JLab Headset Epic Lab Edition

Read below 📖 the manual in Italian for JLab Epic Lab Edition (4 pages) in the Headset category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users

Download PDF

Page 1/4

EPIC LAB EDITION

EARBUDS

We love that you are rocking JLab!

We take pride in our products and fully stand behind them.

YOUR WARRANTY

All warranty claims are subject to JLab authorization

and at our sole discretion. Retain your proof of

purchase to ensure warranty coverage.

Reach out to us at support@jlab.com

or visit jlab.com/contact

jlab.com/register

Product updates How-to tips|

FAQs & more

PAIR UP (BLUETOOTH)

One earbud blinks blue/white = Ready to Pair

Lights on case indicate charging.

Remove earbuds from case.

Remove stickers and place earbuds back in case. 4Select “JLab Epic Lab Edition” in your

Bluetooth settings to connect.

Voice prompt “Bluetooth connected”

followed by will indicate connection.lights off

Bluetooth

Settings

JLab Epic Lab Edition

GO AHEAD, PRESS THE BUTTON

VOLUME DOWN: 1x

VOICE ASSISTANT: 2x

NOISE CONTROLS: Press Hold

EQ CHANGE: 3x

VOLUME UP: 1x

PLAY/PAUSE: 2x

TRACK FORWARD: Press Hold

EQ CHANGE: 3x

ANSWER CALL: 1x

HANG UP CALL: 2x

REJECT INCOMING CALL: Press Hold

PAIR UP (LE AUDIO)

2The earbuds will auto connect to the USB-C dongle and take priority over any previous

Bluetooth connection. Removing the dongle will revert back to previous Bluetooth connections.

Note: The controls are based on Bluetooth connection. Depending on your device and OS, controls will have

varied results with USB-C Dongle connection.

Connect the USB-C dongle into PC/Mac/Android. (Dongle should be connected directly without

any hubs or adapters to work properly.)

LEFT RIGHT

SETUP DONGLE WITH PC (WINDOWS 7/8/10/11)

1. In the Settings menu, click System

2. From the System menu, click Sound

3. In the Output section, select Epic Lab Edition Dongle

4. In the Input section, select Epic Lab Edition Dongle

SETUP DONGLE WITH MAC (macOS 10.10 or HIGHER)

1. Open System Preferences and select the Sound icon

2. Select the Input tab and select Epic Lab Edition Dongle

3. Select Outout tab and select Epic Lab Edition Dongle

4. From this screen, set the Output volume to desired level

MULTIPOINT

Once FIRST device is connected, turn off Bluetooth in

device settings. Earbuds will auto enter Bluetooth Pairing.

Enter your device Bluetooth settings SECOND and

connect to Epic Lab Edition.

Enter your device Bluetooth settings.FIRST

Turn on Bluetooth and connect to Epic Lab Edition.

Bluetooth

Settings

JLab Epic Lab Edition

Bluetooth

Settings

JLab Epic Lab Edition Connect

GET CHARGED (CASE)

GET CHARGED (EARBUDS)

Blue light indicates charging when

placed in the case.

Earbuds will auto power on

and connect when removed.

Left

Charging

Right

Charging

Connect the Epic Lab Edition to computer or

USB 5V 1A (or less) output device.

Place on wireless charging pad.

Blinking white = Charging

Product Specifications

Brand:	JLab
Category:	Headset
Model:	Epic Lab Edition
