Read below 📖 the manual in Italian for Jackery Explorer 300 Plus (51 pages) in the power bank category. This guide has been helpful for 5 people and has been rated 4.5 stars on average by 2 users
Page 1/51
Version: JAK-UM-V1.0
Model: JE-300B
Contact us:
hello.eu@jackery.com
USER MANUAL
Jackery Explorer 300 Plus
5
CONTENTS
GB English 01-08
FR Français 09-16
DE Deutsch 17-24
IT Italiano 25-32
ES Español 33-40
PT Português 41-48
More language versions are supported.
Other language versions of the manual can be downloaded on our official website:
https://de.jackery.com/pages/user-guides
Congratulations on your new Jackery Explorer 300 Plus. Please read this manual carefully before using
the product, particularly the relevant precautions to ensure proper use. Keep this manual in an
accessible place for frequent reference.
In compliance with laws and regulations, the right of final interpretation of this document and all related
documents of this product resides with the Company.
Please kindly notice that no further notifications will be given in case of any update, revision or
termination.
TECHNICAL SPECIFICATIONS
01
CERTIFICATIONS
Product Name
Model No.
Cell Chemistry
Capacity
Weight
Dimensions
Cycle Life
Total Output
AC Output
USB-A Output
USB-C (OUT)
USB-C (IN/OUT)
USB Total Output
Car Port
Charge mode AC Input
Bypass mode AC Input/Output
DC Input (USB-C)
Charge Temperature
Discharge Temperature
Jackery Explorer 300 Plus
JE-300B
LiFePO4
Lithium-ion 22.5Ah / 12.8V DC(288Wh)
Around 8.27 Ibs / 3.75 kg
9.1 x 6.1 x 6.6 in / 23 x 15.5 x 16.7 cm
3000 cycles to 80%+ capacity
300W
230V~50Hz, 1.31A, 300W Rated, 600W Surge peak
15W Max 5V⎓3A
15W Max 5V⎓3A
100W Max 5V 3A, 9V 3A, 15V⎓ ⎓3A, 12V⎓ ⎓3A, 20V⎓5A
USB-C(IN/OUT) : 100W Max, USB-C(OUT)+USB-A : 24W Max
12V⎓10A
220V-240V~50Hz, 10A Max
220V-240V~50Hz, 300W Max
12-27V 5A Max, 100W Max⎓
0~45°C (32~113 )℉
-10~45°C (14~113 ) ℉
GB
Model: JE-300B
English
※ USB Type-C and USB-C are registered trademarks of USB Implementers Forum.
® ®
PACKAGE LIST
3
AC Charge Cable
24
Quick Start Guide
1
Jackery Explorer 300 Plus DC7909 to U CSB-
Adaptor
Version: JAK-UM-V1 .0
Model: JE-300B
Contact u s :
hello.eu @jac kery.com
USER MANUAL
Jac kery Exp lo rer 30 0 P lus
5
5
