Page 1/28
VE-WCN, VE-WCC,
VE-WCSMI, VE-WCSO
Wireless Controller for
Venture TTL 600 Ws Monolight
INSTRUCTIONS
Table of Contents
Introduction 3 ......................................................................
Overview 4-8 ......................................................................
Precautions .................................................................9-10
Installing the Batteries 11 ...................................................
Mounting the Controller 11 .................................................
Powering On...................................................................12
Restoring Factory Presets 12 ..........................................
Power-Saving Feature 12 ................................................
Channel Selection 13 ..........................................................
Setting the Master Group 14 ...............................................
Setting the ID Number 15 ...................................................
TTL Mode 16-18 ..................................................................
High-Speed Sync (HSS) 19 .................................................
Second Curtain Sync (SCS) 19 ............................................
Manual Mode 20 .................................................................
Firing a Test 21 ...................................................................
Lockout Mode 21 ................................................................
Using the Modeling Light 22-23 ..........................................
Cell (Slave) Mode 24 ...........................................................
Troubleshooting 25-26 ........................................................
Specifications 27 ...............................................................
FCC Compliance 27 ............................................................
Warranty 28 ......................................................................
3
Thank you for choosing Impact.
The Impact Venture Wireless Controller is a
compact wireless 2.4 GHz transmitter that provides
the Venture TTL 600 Monolight with through-the-
lens (TTL) and high-speed sync (HSS) functionality.
It allows the user to control and trigger the ash
from a distance of up to 328 (100 m) via 2.4 GHz ′
wireless transmission. It also sets channels,
groups, and ID numbers, and adjusts monolight and
modeling lamp power output.
To use the capabilities of the Venture TTL 600’s
integrated wireless receiver, the Venture Controller
is compatible with most Canon, Nikon, and Sony
cameras with a hot-shoe mount. It can also be
connected to a camera with a PC port via a PC sync
cable.
Introduction
