VFX7-V2
Quick Start Guide
VX Series 7” 4K/3G-SDI On-Camera Tally Field Monitor
What’s Included
1x VXF7-V2 Monitor
1x Sun Hood
1x Power Adapter
1x D-Tap Cable
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re toofilmmakers
Getting Started
Front
A. Front Tally Lights
B. Power LED Indicator
C. F1-F4 Buttons
(Functions can be mapped in Menu)
D. Input Switch Button
E. Exit Button
F. Navigation Buttons
G. Menu / Right Arrow Button
H. Brightness Knob
I. Contrast Knob
J. Chroma Knob
K. Sharpness Knob
A
B C D E F G H I J K
Tally Pin Layout
1 2 3 4 5 6 7 8
Pin # Signal
1 Yellow
2 Red
3 Green
4 5 6 7 NC
8 GND
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com because we’re toofilmmakers
Back
A. Battery Release Button
B. Rear Tally Lights
C. On / Off Switch
D. Mini USB Update Port
E. RJ45 Tally Port
F. HDMI Input / Output Terminal
G. 3.5mm Headphone Output
H. DC 7-24V Power Terminal
I. SDI Input / Output Terminal
A
C
B
D
F G H i
E
Product Specifications
| Brand: | Ikan |
| Category: | Monitor |
| Model: | VXF7-V2 |
