Page 1/9
Operating instructions
AS-i CompactLine module
AC2485
AC2486
AC2487
80227841/01 03/2019
UK
1 2
43
2
Contents
1 Preliminary note 3 ���������������������������������������������������������������������������������������������������
2 Safety instructions 3 �����������������������������������������������������������������������������������������������
3 Functions and features 3 ����������������������������������������������������������������������������������������
4 Installation������������������������������������������������������������������������������������������������������������4
5 Electrical connection 6 ��������������������������������������������������������������������������������������������
5�1 External protective circuitry for inductive loads 6 ���������������������������������������������
6 Addressing �����������������������������������������������������������������������������������������������������������6
6�1 Addressing with the AC1154 addressing unit�������������������������������������������������6
6�2 Infrared addressing 6 ����������������������������������������������������������������������������������������
7 Pin connection / data bits�������������������������������������������������������������������������������������7
8 Maintenance, repair and disposal 8 ������������������������������������������������������������������������
9 Operating and display elements 9 ��������������������������������������������������������������������������
10 Technical data 9 ����������������������������������������������������������������������������������������������������
3
UK
1 Preliminary note
â–ºInstruction
> Reaction, result
Important note
Non-compliance can result in malfunction or interference�
Information
Supplementary note�
2 Safety instructions
• Please read the operating instructions prior to set-up of the device� Ensure that
the product is suitable for your application without any restrictions�
• The unit conforms to the relevant regulations and EC directives�
• Improper or non-intended use may lead to malfunctions of the unit or to
unwanted effects in your application�
• Installation, electrical connection, set-up, operation and maintenance of the
unit must only be carried out by qualified personnel authorised by the machine
operator�
3 Functions and features
• maximum number of modules per master: 62
• threaded bush stainless steel (1�4404), screws stainless steel (1�4578)
• The unit AC2487 can only be operated in conjunction with a version 3�0 master
(master profile M4)�

Product Specifications

Brand: IFM
Category: Not categorized
Model: AC2487

Do you need help?

If you need help with IFM AC2487, ask a question below and other users will answer you
