Page 1/1
1. IEC (male)
Plug into a wall outlet that supplies power to audio equipment,
or plug into a power extension block that supplies power to
audio equipment.
2 Polarity/Earth detection.
The following table depicts the different readings and the
respective LED colour combinations. Where needed, make the
necessary system adjustments.
Tips: Regardless of the LED colour, the SupaNova will always be
actively cancelling noise.
Ver1.0
ifi-audio.com
SupaNova
Polarity Earth Status
2 Polarity error. Live and Neutral
connections are reversed.
Ground error. Earth is missing
or faulty (e.g. resistance too high).
3 Red
Cut-out mode. Over-voltage
or an electrical short.
4Off Off
Red
Red
1
(LED) (LED)
NormalGreenGreen
Green
1 32
Earth Polarity
3 Power outlet IEC.
Connect to your device.
Specifications
Noise reduction: > 40dB (> 100x)
Surge Protection: max. 10,000A @ 775V / 8/20uS
Under operating voltage: Maximum operating rating 10A at
250Vac and 15A at 125Vac
Dimensions: 1.8 m (70.8")
Net weight:
USA: 675 g (1.43 lbs)
EUR: 695 g (1.47 lbs)
Warranty period: 12 months
Specifications are subject to change without notice.
