Page 1/4
EN
Quick guide
THANK YOU FOR BUYING A HOTPOINT PRODUCT
In order to receive a more complete assistance, please
register your product on www . hotpoint . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
FIRST TIME USE
Wait at least two hours, after the installation, before connecting
the appliance to the power supply. Connect the appliance to the
power supply it starts the operation automatically. The ideal storage
temperatures for the food are preset in the factory.
After turning the appliance on, you must wait for 4-6 hours for the
correct storage temperature to be reached for a normally îlled
appliance. Position the antibacterial anti-odour îlter in the fan as
demonstrated in the îlter packaging (if available). If the audible signal
sounds, it means that the temperature alarm has intervened: press the
button to switch oî the acoustic alarms.
CONTROL PANEL
1. LED Light
2. On/Stand-by
3. Freezer and refrigerator compartment
temperature button
2.
1.
3.
ON/STAND-BY
Press the button for 3 seconds to turn the appliance oî. In
Stand-by mode the light in the refrigerator compartment does not turn
on. Press the button again brieîy to reactivate the appliance.
Note: this does not disconnect the appliance from the power supply.
FREEZER AND REFRIGERATOR
COMPARTMENT TEMPERATURE
The three LED indicators indicate the refrigerator compartment
set temperature. It is possible to set a diîerent temperature of the
appliance with the button.
The following adjustments are possible:
LEDs lit Set temperature
High (less cold)
Medium-high
Medium
Medium-low
Low (colder)
FAN*
You can turn the Fan on/oî by pressing the button on the b
shown in the îgure). If the ambient temperature exceeds
27°C, or if drops of water are present on the glass shelves,
it is essential that the fan is on to ensure the proper
preservation of the food. Deactivation of the fan allows
energy consumption to be optimised.
FREEZING FRESH FOOD
Place the fresh food to be frozen in the FREEZING ZONE in the freezer
compartment avoiding the direct contact with the food that is already
frozen. To optimize the freezing speed, the lower drawer can be
removed and the food can be placed directly on the bottom of the
compartment.
FAST COOL FUNCTION (FAST COOLING)
To quickly cool the refrigerator compartment, or
6 hours before putting a large quantity of food
to be frozen in the freezer compartment, turn
on the âFast Coolingâ function by repeatedly
pressing the button until the 3 icons îash
green and then stay constant.
The function automatically turns oî after 30 hours and the
temperature returns to the previous setting when the function is
turned on.
To turn the function oî manually, press the button.
Note: avoid a direct contact between the fresh food and the food that is
already frozen.
To optimize the freezing speed, the lower drawer can be removed and
the food can be placed directly on the bottom of the compartment.
Recommended setting:
⢠Refrigerator compartment: MEDIUM
To avoid food waste, please refer to the recommended setting and storage
times found in the online user manual.
* Available only on certain models
* Available only on certain models
Light system (depending on model)
This product contains a light source of energy
eîciency class G
This product contains 4 lateral light sources of
energy eîciency class F
This product contains a light source of energy
eîciency class G
This product contains 4 lateral light sources of
energy eîciency class F and a top light source
of energy class G
This product contains a top light source of
energy eîciency class G
FREEZER COMPARTMENT
Freezing fresh food
1. It is advisable to set the temperature colder or turn on the Fast Freeze/
Fast Cool* at least four hours before removing the food from the
freezer compartment, to prolong the preservation of the food during
the defrosting phase.
2. To defrost, unplug the appliance and remove the drawers. Leave
the door open to allow the frost to melt. To prevent the water from
escaping during the defrost, it is advised that you place an absorbent
cloth on the bottom of the freezer compartment and wring it out
regularly.
3. Clean the inside of the freezer compartment with the ice scraper and
dry it carefully.
4. Turn the appliance back on and put the food back inside. To remove
the frost on the STOP FROST* accessory, follow the CLEANING.
Ice cubes*
Fill 2/3 of the ice tray with water and put it back in the freezer
compartment. Do not, under any circumstances, use sharp or pointed
objects to remove the ice.
The quantity of fresh food that can be frozen in a speciîc time period is
indicated on the rating plate.
Load limits are determined by baskets, îaps, drawers, shelves etc. Make
sure that these components can still close easily after loading
GENERAL INFORMATION
The drawers, baskets and shelves should be kept in their current position
unless otherwise speciîed in this quick guide. The light system inside the
refrigerator compartment uses LED lights, allowing for better lighting than
with traditional light bulbs, as well as for very low energy consumption.
Doors and lids of the refrigeration appliance should be removed before
disposal in the landîll, to avoid children or animals getting trapped inside.
STOP FROST SYSTEM*
The STOP FROST SYSTEM facilitates the defrost procedure for the
freezer compartment.
The STOP FROST accessory is designed to collect some of the frost
that forms in the freezer compartment and it is easy to remove and
clean, therefore reducing the time needed to defrost the freezer
compartment.
To remove the frost on the STOP FROST accessory follow the cleaning
procedure demonstrated below.
PROCEDURE TO CLEAN THE STOP FROST ACCESSORY
1. Open the freezer compartment door and remove the upper
drawer.
2. Unfasten the STOP FROST accessory and remove it, taking care not
to drop it on the glass shelf below.
Note: if the accessory is jammed or difficult to remove, do not keep
trying to remove it, but proceed with the complete defrost of the freezer
compartment.
3. Close the door of the freezer compartment.
4. Remove the frost on the accessory by rinsing it under running (not
hot) water.
5. Let the accessory drip dry and dry the plastic parts with a soft
cloth.
6. Reinsert the accessory by placing the back part on the projections
shown in îgure, then refasten the handle of the accessory to the
clasps above.
7. Reinsert the upper drawer and close the door of the freezer
compartment.
It is possible to clean the STOP FROST accessory on its own without
completely defrosting the freezer compartment.
Cleaning the STOP FROST accessory regularly helps to reduce the need
to completely defrost the freezer compartment.
Note: the product specifications, including volume and energy, are
calculated without the STOP FROST accessory.
HOW TO STORE FOOD AND BEVERAGE
***
**
Legend
TEMPERATE ZONE
Suggested for storage of tropical fruit, cans, drink, eggs,
sauces, pickles, butter, jam
COOL ZONE
Suggested for storage of cheese, milk, daily food,
delicatessen, yoghurt
COOLEST AREA
Suggested for storage of cold cuts, desserts, meat and
îsh
FRUIT & VEGETABLE DRAWER
FREEZER DRAWERS
FREEZING ZONE DRAWER
(Max cool zone)
Suggested to freeze fresh/cooked food
** For models with "0 ° ZONE" COMPARTMENT the "coolest area" is the one
highlighted in the legend
*** Only for CB310 e CB380 models (refer to the Rating plate located at
side of Fruit and vegetable drawer)
* Available only on certain models
