Read below 📖 the manual in Italian for Hotpoint HA70BE 973 X (16 pages) in the Refrigerator category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/16
EN
Quick guide
1. On/Standby Indicator and Button
2. Black Out Alarm Long Black-Out
Alarm Indicator
(see the below Alarm Table)
3. Fridge Temperature/ Fast Cool
button
4. Fridge Temperature Leds
5. Stop Alarm Button
(see the below Alarm Table)
6. Party Mode Indicator
7. Freezer Temperature Leds
8. Freezer Temperature/ Fast Freeze
button
THANK YOU FOR BUYING A
HOTPOINT-ARISTON PRODUCT
In order to receive a more complete assistance, please
register your product on www . hotpoint . eu/ register
Before using the appliance carefully read the Safety
Instruction.
PRODUCT DESCRIPTION
APPLIANCE
CONTROL PANEL
1. Fruit and vegetable compartment*
2. Food Care Zone 0°C/
Safe Defrost*
3. Freezer and storage compartment
4. Dairy Shelf*
5. Movable shelves*
6. Temperature Indicator*
7. Bottle rack*
8. Bottle shelf*
9. Levelling feet
* Varies by number and/or position,
available only on certain models.
3
6
7
8
9
2
4
5
1
1
2
3
4
7
5
6
8
ACCESSORIES
BOTTLE RACK
FIRST TIME USE
HOW TO START THE APPLIANCE
After plugging the appliance to the mains, it starts the
operation automatically. After starting the appliance, wait at
least 4-6 hours before placing food into the fridge and into
the freezer compartment.
When the appliance is connected to the power supply, the
display lights up and all the icons appear on the display for
approximately 1 second. The default (factory) values of the
fridge - freezer compartment settings light-up.
DAILY USE
FUNCTIONS
ON/STANDBY INDICATOR /BUTTON
To put the product in Stand-by, press and hold for 3 seconds.
All the icons turn o except:
FRIDGE TEMPERATURE
To adjust the Fridge Temperature, press the Fridge °C
button. The Fridge Temperature can be adjusted between
+2°C and + 8°C, as shown by the Fridge Temperature LEDs.
FAST COOL
Using Fast Cool function it is possible to increase the cooling
in the refrigerator compartment. The use of this function is
recommended when placing a very high quantity of food
in the refrigerator compartment. Press & hold for 3 sec.
the Fridge °C button to activate Fast Cool function. When
activated, the Fast Cool indication will be displayed by the
Fridge Temperature LEDs as shown in the beside sequence.
The function is automatically disabled after 6 hours, or can be
manually disabled by pressing Fridge °C button.
FREEZER TEMPERATURE
To adjust the Freezer Temperature, press the Freezer °C
button. The Freezer Temperature can be adjusted between
-16°C and -24°C, as shown by the Freezer Temperature LEDs.
FAST FREEZE
The use of this function is recommended when placing a very
high quantity of food to be frozen in the freezer compartment.
24 hours before freezing fresh food, press & hold for 3 sec.
the Freezer button to activate the Fast Freeze function. When
activated, the Fast Freeze indication will be displayed by the
Freezer Temperature LEDs as shown in beside sequence.
After 24 hours place the food to be frozen in the upper
basket of freezer compartment. The function is automatically
disabled after 48 hours, or can be manually disabled by
pressing Freezer °C button.
PARTY MODE
Use this function to chill drinks inside the freezer
compartment. Press the Party Mode button to activate/
deactivate this function. Once the Party mode has been
activated, after 30 minutes an acoustic alarm will remind you
to remove drink/bottle from the freezer compartment. To
mute the alarm press the Stop alarm button, or deactivate the
function pressing the Party mode button.
Important: do not leave the bottle inside the freezer
compartment longer than the function is active (30 minutes).
SMART DISPLAY
This optional function can be used to save energy. To activate
the Smart Display, press Fridge °C and Freezer °C buttons
at the same time for 3 seconds until an audible signal sounds.
To deactivate this function repeat the same procedure.
Remember that this function does not disconnect the
appliance from the power supply, but only reduce the power
consumed by external display.
See Use and Care Guide for more details on functions / see last
page for information on how to obtain the Use and Care Guide
EN
FOOD CARE ZONE 0°C/ SAFE DEFROST*
A compartment designed to keep delicate food such as meat
and sh fresh. The low temperature in the compartment
makes it possible to store the food for up to one week -
tests performed on meat products - without changing its
nutrients, appearance and avour. The compartment is also
very suitable for healthy food defrosting, as low-temperature
defrosting prevents any proliferation of microorganisms,
while protecting its taste and organoleptic properties.
It is not suitable for fruit, vegetables and green salad. But it
can be used for stued fresh pasta and even cooked food or
leftovers.
TEMPERATURE INDICATOR*
Temperature indicator informs you if the temperature in this
cavity is cold enough for storage with the word “OK”.
1. Check that OK appears clearly on the indicator light (see
the picture below).
2. If the word “OK” does not appear it means that the
temperature is too high: set a lower temperature and wait
approximately 10 hours until the temperature has been
stabilised.
3. Check the indicator light again: if necessary, readjust it
following the initial process. If large quantities of food have
been added or if the refrigerator door has been opened
frequently, it is normal for the indicator not to show OK.
Wait at least 10 hours before adjusting the REFRIGERATOR
OPERATION knob to a higher setting.
SHELVES*
Due to the special guides the shelves are removable and the
height is adjustable, allowing easy storage of large containers
and food.
FRUIT AND VEGETABLE BIN*
The salad crispers tted inside the fridge have been specially
designed for the purpose of keeping fruit and vegetables
fresh and crisp. Open the humidity regulator (position B)
if you want to store food in a less humid environment like
fruit, or close it (position A) to store food in a more humid
environment like vegetable.
A
B
A
B
ALARM TABLE
ALARM TYPE SIGNAL CAUSE SOLUTION
Door open
alarm
The acoustical alarm is activated
and the Alarm Indicator blinks.
The door has remained open
for more than 2 minutes.
Close the door or press the Stop Alarm
to mute the acoustical alarm.
Temparature
Alarm
The Temperature LEDs display
blinks (°C) and the Alarm
Indicator remains on.
The inside freezer
temperature is not adequate.
Press the Stop Alarm button ;
the acoustical alarm stops, the
Temperature Display (°C) blinks and the
Alarm Indicator remains on until a
temperature < -10°C is reached.
Long Black-
Out alarm The Black Out Alarm icon
remains on, the Alarm indicator
blinks.
Prolonged power failure,
able to cause the inside
temperature to increase to
0°C.
Press the Stop Alarm button ;
the acoustical alarm stops, the
Temperature Display (°C) blinks and the
Alarm Indicator remains on until a
temperature < -10°C is reached.
SOME OF THE FUNCTIONAL SOUNDS
YOU MIGHT HEAR
A hissing sound when switching on the
appliance for the rst time or after a long
pause.
A gurgling sound when refrigerant uid
enters into the pipes.
BRRR sound is from the compressor
running.
Buzzing sound when water valve or fan
start working.
A cracking sound when compressor
starts.
The CLICK is from the thermostat which
adjusts how often the compressor is
running.
