Page 1/21
ELLIPTICAL GUIDE
GUIDE DE L’EXERCISEUR ELLIPTIQUE
GUÍA DE LA MÁQUINA ELÍPTICA
JHT14_GUIDE_EP_Rev1_9.indd 1 8/13/14 8:41 AM
2
3 ENGLISH
14 FRANÇAIS
26 ESPAÑOL
BASIC OPERATION
JHT14_GUIDE_EP_Rev1_9.indd 2-3
4
LOCATION OF THE ELLIPTICAL
Place the elliptical on a level surface. There should be one foot of clearance in front of the elliptical
for the power cord. For ease of access, there should be an accessible space preferentially on both
sides of the elliptical equal to 36” (915 mm) to allow a user access to the machine from either side.
Do not place the elliptical in any area that will block any vent or air openings. The elliptical should
not be located in a garage, covered patio, near water or outdoors.
POWER
Your elliptical is powered by a power supply. The power must be plugged into the power jack,
which is located in the front of the machine near the stabilizer tube. Some ellipticals have a power
switch, located next to the power jack. Make sure it is in the position. Unplug cord when not in ON
use. NOTE: Some ellipticals have an switch located behind the console.ON/OFF
Never operate product if it has a damaged cord or plug, if it is not working
properly, if it has been damaged, or immersed in water. Please reference contact
information on the back cover of the INFORMATION CARD for assistance.
FOOT POSITIONING
Your elliptical offers a variety of foot positions. Moving your foot to the forward most position of the foot pad increases your step height,
which will create a feel similar to a step machine. Placing your foot toward the back of the foot pad decreases your step height and
creates more of a gliding feel, similar to a smooth walk or run. Always make sure your entire foot is secured on the foot pad.
Your elliptical also allows you to pedal both forward and backwards to offer a variation to your workout and to focus on other major leg
muscle groups such as your hamstrings and calves.
WARNING
36”
915 mm
36”
915 mm
JHT14_GUIDE_EP_Rev1_9.indd 4-5
