Page 1/24
R48RecyclingMower
Code445E,446E,447E
SerialNo.280R00001,280S00001,or280T00001and
Up ManualPartNo.111-2087RevB
Introduction
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoidinjury
andproductdamage.Youareresponsibleforoperating
theproductproperlyandsafely.
Wheneveryouneedservice,genuineparts,oradditional
information,contactanAuthorizedServiceDealerand
havethemodelandserialnumbersofyourproduct
ready.Figure1identiesthelocationofthemodeland
serialnumbersontheproduct.
Figure1
1.Modelandserialnumberplate
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafetyalertsymbol
(Figure2),whichsignalsahazardthatmaycauseserious
injuryordeathifyoudonotfollowtherecommended
precautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
Contents
Introduction.................................................................2
Safety...........................................................................3
GeneralLawnMowerSafety.................................3
SoundPressure.....................................................4
SoundPower........................................................4
Vibration,Hand/arm...........................................4
SafetyandInstructionalDecals.............................5
Setup............................................................................6
UnfoldingtheHandle...........................................6
FillingtheEnginewithOil....................................6
InstallingtheFuse(Model447EOnly)..................7
ChargingtheBattery(Model447EOnly)...............7
ProductOverview........................................................8
Operation.....................................................................8
FillingtheFuelTank.............................................8
CheckingtheEngineOilLevel..............................8
AdjustingtheCuttingHeight................................9
StartingtheEngine...............................................9
UsingtheSelf-propelDrive(Models446Eand
447EOnly)....................................................10
StoppingtheEngine...........................................10
RecyclingtheClippings.......................................10
BaggingtheClippings.........................................10
Rear-dischargingtheClippings............................11
OperatingTips...................................................11
Maintenance...............................................................13
RecommendedMaintenanceSchedule(s)................13
PremaintenanceProcedures....................................13
PreparingforMaintenance.................................13
Lubrication.............................................................14
LubricatingtheWheelGears...............................14
EngineMaintenance...............................................14
ReplacingtheAirFilter.......................................14
ChangingtheEngineOil....................................14
ElectricalSystemMaintenance................................15
ChargingtheBattery(Model447E
Only)..............................................................15
ReplacingtheFuse(Model447EOnly)...............15
DriveSystemMaintenance.....................................16
AdjustingtheSelf-propelDrive...........................16
BladeMaintenance.................................................17
ReplacingtheBlade............................................17
Cleaning.................................................................18
CleaningtheMower............................................18
Storage.......................................................................18
PreparingtheMowerforStorage........................18
RemovingtheMowerfromStorage.....................18
©2008—HayterLimited
2
PrintedintheUSA.
AllRightsReserved
Safety
Improperlyusingormaintainingthismowercan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructions.
Thismowerwasdesignedandtestedforreasonablysafe
service;however,failuretocomplywiththefollowing
instructionsmayresultinpersonalinjury.
Toensuremaximumsafety,bestperformance,and
togainknowledgeoftheproduct,itisessential
thatyouandanyotheroperatorofthemowerread
andunderstandthecontentsofthismanualbefore
theengineiseverstarted.Payparticularattention
tothesafetyalertsymbol(Figure2)whichmeans
Caution,Warning,orDanger—“personalsafety
instruction.”Readandunderstandtheinstruction
becauseithastodowithsafety.Failuretocomply
withtheinstructionmayresultinpersonalinjury.
GeneralLawnMowerSafety
Thefollowinginstructionshavebeenadaptedfromthe
ISO5395.
Thiscuttingmachineiscapableofamputatinghands
andfeetandthrowingobjects.Failuretoobservethe
followingsafetyinstructionscouldresultinserious
injuryordeath.
Training
•Readtheinstructionscarefully.Befamiliarwiththe
controlsandtheproperuseoftheequipment.
•Neverallowchildrenorpeopleunfamiliarwiththese
instructionstousethemower.Localregulationscan
restricttheageoftheoperator.
•Keepinmindthattheoperatororuserisresponsible
foraccidentsorhazardsoccurringtootherpeopleor
theirproperty.
•Understandexplanationsforallpictogramsusedon
themowerorintheinstructions.
Petrol
WARNING-Petrolishighlyammable.Takethe
followingprecautions.
•Storefuelincontainersspecicallydesignedforthis
purpose.
•Refueloutdoorsonlyanddonotsmokewhile
refueling.
•Addfuelbeforestartingtheengine.Neverremove
thecapofthefueltankoraddpetrolwhilethe
engineisrunningorwhentheengineishot.
•Ifpetrolisspilled,donotattempttostarttheengine
butmovethemowerawayfromtheareaofspillage
andavoidcreatinganysourceofignitionuntilpetrol
vaporshavedissipated.
•Replaceallfueltankandcontainercapssecurely.
Preparation
•Whilemowing,alwayswearsubstantialfootwearand
longtrousers.Donotoperatetheequipmentwhen
barefootorwearingopensandals.
•Thoroughlyinspecttheareawheretheequipmentis
tobeusedandremoveallstones,sticks,wires,bones
andotherforeignobjects.
•Beforeusing,alwaysvisuallyinspecttoseethat
guards,andsafetydevices,suchasdeectorsand/or
grassbags,areinplaceandworkingcorrectly.
•Beforeusing,alwaysvisuallyinspecttoseethatthe
blades,bladeboltsandcutterassemblyarenotworn
ordamaged.Replacewornordamagedbladesand
boltsinsetstopreservebalance.
Starting
•Disengageallbladeanddriveclutchesandshiftinto
neutralbeforestartingtheengine.
•Donottiltmowerwhenstartingtheengineor
switchingonthemotor,unlessthemowerhastobe
tiltedforstarting.Inthiscase,donottiltitmorethan
absolutelynecessaryandliftonlythepart,whichis
awayfromtheoperator.
•Starttheengineorswitchonthemotorcarefully
accordingtoinstructionsandwithfeetwellaway
fromtheblade(s)andnotinfrontofthedischarge
chute.
Operation
•Nevermowwhilepeople,especiallychildren,orpets
arenearby.
•Mowonlyindaylightoringoodarticiallight.
•Stayalertforholesintheterrainandotherhidden
hazards.
•Donotputhandsorfeetnearorunderrotatingparts.
Keepclearofthedischargeopeningatalltimes.
•Neverpickuporcarryalawnmowerwhilethe
engineisrunning.
•Useextremecautionwhenreversingorpullinga
pedestriancontrolledlawnmowertowardsyou.
•Walk,neverrun.
•Slopes:
3
