 C‐TM‐SEATMT_INST_7‐10



INSTALLATION INSTRUCTIONS

C-TM-SEATMT

Universal Seat Mount Platform for Laptop Computers

TOOLS REQUIRED:

Ratchet Wrench and Socket Set Phillips Screw driver

7/16” Open End Wrench



PARTS and MOUNTING HARDWARE:

QTY DESCRIPTION PART #

1 Seat Mount Backing Plate CM002510

1 Ratchet Strap with Hooks GSM20085

Allotherhardwarecomesalread

attachedtoseatmountassembl

orwithothero

tional

arts.

Always!

¾ ReadallinstructionsbeforeinstallinganyHavisInc,products.

¾ Useonlyhardwareprovidedwithinstallkit.

¾ Forproductsupport,visittheInstallInstructionsSectionofourwebsiteat

http://havis.com/Installation/Installation.html,emailtechnicalsupport@havis.comorcall1‐800‐

524‐9900andaskfortechnicalsupport.

C-TM-SEATMT

ASSEMBLY DRAWING

CM002510 Seat Mount Backing Plate

GSM20085 Ratchet Strap with Hooks



 C‐TM‐SEATMT_INST_7‐10



AssembleStrapwithHooksandBacking

plateasshowninphotoand/ordrawing.

Ratchetonpassengersideworksbest.

DockingStationwithoptionalC‐HDM‐303

andC‐MD‐202shown.

PlaceSeatMountassemblyonseatandslip

thebackingplatethroughthegapbetween

theseatbackandseat

ad.

BoltLPS‐XXXpowersupplytothebottom

ofDockingStationandattachDocktoseat

mountassemblywithC‐MD‐202Tilt

Swivel.Partssoldse

aratel

.

Beforeattachingadditionalparts,placethemain

assemblyontheseattop.Adjusttherearplateso

itisagainsttheseatback.

Adjusttheforwardplatesoitwrapscloselyover

thefrontofseat

ad.

Note:Anoptionaloffsetadaptorcanbe

usedtopositioncomputerclosertocenter

ofvehicle.C‐HDM‐303shown.



 C‐TM‐SEATMT_INST_7‐10



Thisplatformcanaccommodatean

optionalprintermount.



Adjustbracketstopositionthecomputer

inthedesiredlocation.

Plugpowercableintothe12voltpowersource.



NOTE:Atowelbetweentheseatandseat

mountplatformwillprotecttheseat.

Pullstrapslackthroughratchet

mechanismandtightentheratchetsothe

latformisfirml

attachedtoseat.

Attachbothhooksunderneaththeseattoa

sturdylocation.

DoNOTattach movinto



artsorwires.



Positionbackingplatesoitwillnotpull

backthroughthefrontofseat.

Product Specifications

Brand:	Havis
Category:	Car kit
Model:	C-TM-SEATMT
