GIGABYTE will reduce paper use in order to fulîš¿ll the responsibilities of a global citizen.
Also, to reduce the impacts on global warming, the packaging materials of this product
are recyclable and reusable. GIGABYTE works with you to protect the environment.
For more product details, please visit GIGABYTE's website.
TRX50 AI TOP
User's Manual
Rev. 101
Copyright
© 2024 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the property of GIGABYTE.
Changes to the speciîš¿cations and features in this manual may be made by GIGABYTE without
prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or
published in any form or by any means without GIGABYTE's prior written permission.
îš„For detailed product information, carefully read the User's Manual.
îš„For quick set-up of the product, refer to the Quick Installation Guide on GIGABYTE's
website.
https://download.gigabyte.com/FileList/Manual/mb_manual_quick-guide_amd-trx.pdf?m=sw
For product-related information, check on our website at: https://www.gigabyte.com
Identifying Your Motherboard Revision
The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"
means the revision of the motherboard is 1.0. Check your motherboard revision before updating
motherboard BIOS, drivers, or when looking for technical information.
Example:
- 3 -
Table of Contents
Chapter 1 Product Introduction .......................................................................................4
1-1 Motherboard Layout ............................................................................................ 4
1-2 Motherboard Block Diagram ............................................................................... 5
1-3 Box Contents ...................................................................................................... 6
Chapter 2 Hardware Installation ....................................................................................7
2-1 Installation Precautions ....................................................................................... 7
2-2 Product Speciîš¿cations ........................................................................................ 8
2-3 Installing the CPU and CPU Cooler .................................................................. 11
2-4 Installing the Memory ........................................................................................ 14
2-5 Installing an Expansion Card ............................................................................ 16
2-6 Back Panel Connectors .................................................................................... 17
2-7 Onboard Buttons and LEDs .............................................................................. 19
2-8 Internal Connectors........................................................................................... 21
Chapter 3 BIOS Setup ..................................................................................................35
Chapter 4 Installing the Operating System and Drivers ................................................37
4-1 Operating System Installation ........................................................................... 37
4-2 Drivers Installation ............................................................................................ 38
Chapter 5 Appendix ......................................................................................................39
5-1 Conîš¿guring a RAID Set..................................................................................... 39
5-2 Debug LED Codes ............................................................................................ 40
Regulatory Notices ...................................................................................................... 44
Contact Us .................................................................................................................. 47
