Page 1/6
Platinum
Residential Gateway
Installation Guide
Revision 1.9. - September 2018
Copyright © 2018 Genexis B.V. All rights reserved.
Hereby, Genexis declares that the radio equipment type Platinum-7000 is in compliance with Directive 2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: https://genexis.eu/red/platinum-7000
Genexis assumes no responsibility for any inaccuracies in this document.
Genexis reserves the right to change, modify, transfer, or otherwise revise this publication without notice.
Contents
Models Supported ........................................................................................................................................................... 3
Box Content ..................................................................................................................................................................... 4
Button Overview ............................................................................................................................................................... 6
Port Overview ................................................................................................................................................................... 8
Installation ...................................................................................................................................................................... 10
LAN (Network) Setup ...................................................................................................................................................... 13
Wireless Setup ................................................................................................................................................................ 15
LED Status ...................................................................................................................................................................... 18
Troubleshooting ............................................................................................................................................................. 20
Advanced Conguration ................................................................................................................................................ 21
Safety and Care .............................................................................................................................................................. 21
Appendix: Installing an SFP ............................................................................................................................................ 22
Notes .............................................................................................................................................................................. 23
3
Model CATV Port overview
Platinum-6820 No
Platinum-6840 No
Platinum-6880 Yes
Platinum-7840 No
Platinum-7870 Yes
Models Supported
On the label at the bottom of your platinum (as shown on page 5) you can look up your Platinum model.
In the table below you see a full overview of all the models.
Power
1 2 3 4 1 2
Power
1 2 3 4 1 2
Internet
Power
1 2 3 4 1 2
Internet
Power
1 2 3 4 1 2
Power
1 2 3 4 1 2
