Generac G0072250 Manual
Read below 📖 the manual in Italian for Generac G0072250 (40 pages) in the Generator category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/40
SAVE THIS MANUAL FOR FUTURE REFERENCE
®
Owner’s Manual
60 Hz Air-Cooled Generators
10 kW to 26 kW
Para español, visita: http://www.generac.com/service-support/product-support-lookup
Pour le français, visiter : http://www.generac.com/service-support/product-support-lookup
Register your Generac product at:
WWW.GENERAC.COM
1-888-GENERAC
(888-436-3722)
(000209b)
WARNING
Loss of life. This product is not intended to
be used in a critical life support application.
Failure to adhere to this warning could result
in death or serious injury.
ii Owner’s Manual for 60 Hz Air-Cooled Generators
Use this page to record important information about this generator.
Record the information found on the unit data
label on this page. See General Information
for the location of the unit data label. The unit
has a label plate affixed to the inside partition,
to the left of the control panel console as
shown in , , or
Figure 2-1 Figure 2-2 Figure 2-
3 Operation
. See for directions on how to
open the top lid and remove the front panel.
Always supply the complete model and serial
numbers of the unit when contacting an Inde-
pendent Authorized Service Dealer (IASD)
about parts and service.
Operation and Maintenance: Correct main-
tenance and care of the unit ensures a mini-
mum number of problems, and keeps
operating expenses at a minimum. It is the
operator’s responsibility to perform all safety
inspections, to verify all maintenance for safe
operation is performed promptly, and to have
the equipment inspected periodically by an
IASD. Normal maintenance, service, and
replacement of parts are the responsibility of
the owner/operator and are not considered
defects in materials or workmanship within the
terms of the warranty. Individual operating
habits and usage may contribute to the need
for additional maintenance or service.
When the generator requires servicing or
repairs, Generac recommends contacting an
IASD for assistance. Authorized service tech-
nicians are factory-trained and are capable of
handling all service needs. To locate the near-
est IASD, please visit the dealer locator at:
www.generac.com/Dealer-Locator.
Model:
Serial:
Production Date:
Volts:
LPV Amps:
NG Amps:
Hz:
Phase:
Controller P/N:
STA MAC ID:
SSID:
(000393a)
WARNING
CANCER AND REPRODUCTIVE HARM
www.P65Warnings.ca.gov.
Owner’s Manual for 60 Hz Air-Cooled Generators iii
Table of Contents
Section 1: Safety Information
Introduction ..................................... 1
Read This Manual Thoroughly ............1
Safety Rules.................................... 1
How to Obtain Service ........................2
General Hazards............................. 2
Exhaust Hazards............................. 2
Electrical Hazards ........................... 3
Fire Hazards.................................... 3
Explosion Hazards .......................... 3
Battery Hazards .............................. 4
Section 2: General Information
Generator Components and
Control Locations ............................ 5
Data Decals..................................... 8
Specifications .................................. 9
Generator ............................................9
Engine .................................................9
Protection Systems ....................... 10
Emissions...................................... 10
Fuel Requirements........................ 10
Battery Requirements ................... 10
Battery Charger............................. 11
Engine Oil Requirements .............. 11
Activating the Generator ............... 11
Wi-Fi Module ................................. 11
Replacement Parts........................ 11
Accessories................................... 11
Section 3: Operation
Site Prep Verification..................... 13
Generator Enclosure ..................... 13
Opening the Lid .................................13
Front Access Panel Removal ............13
Intake Side Panel Removal ...............14
Main Line Circuit Breaker (Generator
Disconnect) .......................................14
LED Indicator Lights ..........................14
Generator Emergency Shutdown
Switch ........................................... 15
Control Panel Interface ................. 15
Using the AUTO/OFF/MANUAL
Buttons.......................................... 15
Operating Modes........................... 16
Interface Menu Displays................ 16
LCD Panel .........................................16
Menu System Navigation .............. 17
Setting the Exercise Timer............ 19
Battery Charger ............................. 19
Manual Transfer Operation............ 19
Transfer to Generator Power
Source ...............................................19
Transfer to Utility Power Source ........20
Automatic Transfer Operation ....... 20
Automatic Sequence of
Operation....................................... 20
Utility Failure ......................................20
Cranking ............................................20
Cold Smart Start ................................20
Cleaning Cycle ..................................21
Load Transfer ....................................21
Shutting Generator Down While Under
Load or During a Utility Outage ..... 21
Section 4: Maintenance
Maintenance .................................. 22
Preparing for Maintenance ............ 22
Performing Scheduled
Maintenance .................................. 22
Service Schedule........................... 23
Maintenance Log ...................................23
Checking Engine Oil Level ............ 24
Engine Oil Requirements ..................24
Changing the Oil and Oil Filter ...... 24
Servicing the Air Cleaner............... 25
Spark Plug(s)................................. 26
Valve Clearance Adjustment ......... 26
Checking Valve Clearance ................26
Adjusting Valve Clearance ................27
Battery Maintenance...................... 27
Inspecting the Battery ........................28
Cleaning the Sediment Trap.......... 29
Post Maintenance Checks............. 29
Performing Fuel System Leak Test ...29
Attention After Submersion............ 30
Corrosion Protection ...................... 30
Remove From and Return To
Service Procedure ......................... 30
Remove From Service .......................30
Return to Service ...............................30
Section 5: Troubleshooting /
Quick Reference Guide
Generator Troubleshooting............ 32
Quick Reference Guide ................. 34
