INSTRUCTION MANUAL/MANUAL DE USUARIO/
MODE D’EMPLOI/MANUAL DE INSTRUÇÕES
MALIBU-212P
PORTABLE SPEAKER
ALTAVOZ PORTÁTIL
HAUT-PARLEUR PORTABLE
COLUNA PORTÁTIL
EN
- 2 -
DESCRIPTION
- High power and sound quality provided by its high-efficiency Class D amplifier.
- They integrate all the necessary elements for a live performance or talk: 2 wireless microphones (1
handheld and 1 headset), 2 microphone inputs, 1 auxiliary input, USB/SD/MP3 player, mixer, graphic
equaliser, speaker and amplifier.
- Its trolley together with a rechargeable Li-ion battery of great capacity and autonomy, make it very
versatile and adaptable to a multitude of uses.
CONTROLS AND FUNCTIONS
REAR PANEL
1
2
3
8
6
4
9
7
5
11
10 12
13
14
16
15
17
18
20
19
21
23
22
21
25
24
22
23
26
27
28
29
30
31
1.- SD memory card connection port.
2.- Connection port for USB storage devices.
3.- Information screen of the USB/SD/MP3 player module.
4.- Infrared receiver for the remote control.
5.- MODE : allows you to select between the different audio sources available.
6.- (VOL-) / (VOL+): a short press on these buttons allows you to skip to the previous/next audio track. A
long press on these buttons allows you to decrease/increase the volume of the player.
EN
- 3 -
7.- : allows you to change the play and repeat mode of the player (repeat all, repeat folder, repeat 1 and
random play).
8.- (FOLDER): A short press on this button starts/pauses playback. A long press displays the folder in
playback.
9.- MIC 2: microphone input 2, 6.3 mm jack plug.
10.- MIC 1: microphone input 1, XLR connector.
11.- MIC 1 VOL, MIC 2 VOL: volume controls for microphone inputs 1 and 2.
12.- 5-band graphic equaliser.
13.- LINE OUT: line level stereo output, 2 x RCA connectors.
14.- LINE IN: line level stereo auxiliary input, 2 x RCA connectors.
15.- Auxiliary input operation selector. Allows you to select between the LINE IN input and the player module.
16.- VOL: volume control of the line level input and USB/SD/MP3 player.
17.- POWER: portable amplifier power indicator light.
18.- PEAK: signal peak indicator light. It lights up when an input signal is detected with a level which is too high
or when there is an excessive output level that may cause a fault.
19.- MASTER: output volume control of the final mix of all inputs.
20.- ECHO: control for the adjustment of the number of repetitions of the echo effect of the microphone inputs.
21.- Independent telescopic antennas for channels A and B.
22.- REF A-B: adio frequency signal level indicator lights.
23.- CH A-B VOL: volume controls for the wireless microphones.
24.- ON/OFF: switch to activate/deactivate the wireless microphone receiver modules.
25.- Indicator light for the wireless microphone receiver modules.
26.- External power supply terminals 12 V DC.
27.- Charging indicator lights battery charging and green when the charging
. Illuminates Turns red during
process is complete.
28.- Battery charge level indicators.
29.- Power supply voltage selector 115/230 V.
30.- Input for AC power cord connection.
31.- General on/off switch of the loudspeaker.
HAND-HELD MICROPHONE
OFF
ON
1 2 3
1.- Use two LR-6AA alkaline batteries.
2.- Operation switch. It has 3 positions, ON, STANDBY (central position) and OFF. Place it in the ON position
for operation. Place the switch in the position STANDBY to save battery power and the microphone will
turn on immediately when switching to ON.
3.- Battery indicator light. It will turn green when the charge level is correct and red when the batteries are
low.
