Fiilex P3 Color Manual
Read below 📖 the manual in Italian for Fiilex P3 Color (2 pages) in the Relief category. This guide has been helpful for 3 people and has been rated 4.5 stars on average by 2 users
Page 1/2
1. 4 Leaf Barndoor
2. V-Mount
3. Barndoor Slot
4. Accessory Lock
5. Barndoor Holder
6. Side Air Vents
7. Yoke Knob
8. DMX Cable
9. USB Type-C Port
(For updating firmware & 5V/1A)
10. Accessory Lock Release
11. Intensity Control Knob
12. OLED Display
13. Menu Knob
14. Light Control Output Jack
15. DC Power Input Jack
16. ON/OFF Button
17. Light Stand Adapter
18. Power Adapter
19. Yoke
• DO NOT look into the light source. Be cautious of the high-intensity beam.
• DO NOT disassemble P3 Color. This will void the warranty.
• DO NOT install P3 Color in damp or wet locations.
• DO NOT obstruct the fixture’s air vents.
• Use safety cable (not included) when rigging P3 Color overhead.
• Only use Fiilex approved power supply and accessories. Failure to do so may damage the fixture.
• Shields, lenses or ultraviolet screens shall be changed if they have become visibly damaged to such an extent that their
effectiveness is impaired, for example by cracks or deep scratches.
• The lamp shall be changed if it has become damaged or thermally deformed.
• The luminaire is intended for professional use only.
Parts Diagram
2345 1
7
6
8
17
13
14
16
15
18
19
9 10 11 12
Safety Instructions
210315A
User Guide
1689 Regatta Bl evd. Richmond, CA 94804 | (510) 620-5155 | fiil x@fiilex.com www.fiilex.com
Settings
Fixture Operation
Mode Selection
Fixture Control
Use Menu Knob to enter MODES, then navigate through modes and press Menu Knob to select the desired mode.
Press the Menu Knob twice to exit the selected Mode and return to the Main Menu.
1 Manual / Local :
Use Intensity Control Knob or the
Menu Knob
to control the parameters.
Press the Menu knob for 3 seconds to lock the screen. Press for 3 seconds again to unlock.
2
DMX / RDM :
Display shows DMX connection status, NO DMX or DMX OK.
Use
Menu Knob
to enter and edit SETTINGS. Navigate to the right to access additional settings.
View current fixture firmware versions and fixture temperature.
Info
Product Specifications
| Brand: | Fiilex |
| Category: | Relief |
| Model: | P3 Color |
