Page 1/2
Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland
tel. +48 61 822 05 11, fax +48 61 822 05 59
e-mail: oce@ferguson-digital.eu
www.ferguson-digital.eu
Twin Tuner Receiver
for TV
Triple OS!
Linux
Enigma 2
Linux
Ferguson Sp. z o.o., ul. Dworska 1, 61-619 Poznań, Poland
tel. +48 61 822 05 11, fax +48 61 822 05 59
e-mail: oce@ferguson-digital.eu
www.ferguson-digital.eu
1. WiFi Antenna
2. DVB-S2
3. DVB-S2
4. AV
5. S/PDIF
6. HDMI
7. USB 3.0
8. 2 x USB 2.0
9. Ethernet
10. DC INPUT
EAN: 5907115003047
Embalagens: 10 peças
2
1
3 4 5 9
Main Chipset
• HiSilicon HI3798C V200 up to 1.6GHz, Quad-Core
• CPU Architecture: ARM Cortex A53
• GPU: ARM Mali T720 (OpenGL ES 3.1,
3.0, 2.0, 1.1 and OpenCL 1.1)
• SDRAM: 2GB DDR3 SDRAM
• Storage: 16GB eMMC (system and
recovery partitions included)
DVB-S2 Tuner
• Input Connector: F-Type Female
• Frequency Range: 950MHz to 2150MHz
• Signal Level: -25 to -70dBm
• LNB Power & Polarisation: Vertical: +13.5V ± 0.5V Max
250mA; Horizontal: +18.5V ± 0.5V Max 250mA
• 22KHz Tone: Frequency: 22KHz ± 4KHz, 0.6Vp-p ± 0.2Vp-p
• Diseqc Control: Version 1.0, 1.2, USALS Compatible
• Demodulation: QPSK & 8PSK
• Input Symbol Rate: DVB-S : 1 ~ 55Mbps
/ DVB-S2 : 1 ~ 45Mbps
Technical Data
• Transport Stream: ITU-T H.265/HEVC & H.264, ISO/
IEC 13818-2 MPEG-2, AVS&AVS+, VC1, VP6, VP8, VP9
• Prole Level: ITU-T H.265 Main 10 Prole@
L5.1 high-tier, MPEG-2 MP@HL
• Input Rate: Max. 160Mbit/s (H.265)
• Video Format: 4:3, 16:9, Letter Box, Pan&Scan
• Video Resolution: 10bit, Up to
4096x2160px@60fps, HDR 10 Support
• Audio Decoding: MPEG I&II, MP3, Dolby True
HD & Digital Plus, AAC-LC, HE-AAC V1/V2
• Audio Mode: Stereo/Mono/Left/Right/Exchange
• Bluetooth: 4.0 + EDR
• HDMI: HDMI 2.0a TX with HDCP 2.2, 4K 10bit UHD @60Hz
up 4096x2160px, 1080p/i, 720p/i, 576p/i, 480p/i
• Ethernet: RJ45 10/100/1000Mb Ethernet interface
• Wi-Fi: DualBand 2,4/5GHz 802.11a/b/g/n/ac
• USB: 1x USB 3.0 port, 2x USB 2.0 port
• Ports: AV, HDMI 2.0a HDCP 2.2, HDCP1.4, USB
2.0, USB 3.0, S/PDIF, LAN 10/100/1000Mbit,
DC 12V/3A, DVB-S2, Smart Card Slot
• Software: Dual OS Android TV 8 and
Linux Debian or Enigma 2
• Video Support: HDTV, SDTV MPEG-2, MPEG-4,
H.264, HEVC/H.265, AVS, DivX 2K/4K decoding
• Video Formats Support: MKV, MP4, WMV, MPG,
MPEG, DAT, AVI, MOV, ISO, others via applications
• Video Containers Support: MKV(h.264, HEVC/h.265),
WMV, MP4, RM, RMVB, TS, AVI, VOB, MOV
(h.264,HEVC/h.265), ASF, 3GP, others via applications
• Audio Support by passtrough: AC3/Dolby Digital
5.1, E-AC/Dolby Digital +5.1, Dolby Digital +7.1,
TrueHD 5.1, TrueHD 7.1, Dolby Atmos 7.1, DTS
HD Master, DTS High Resolution, DTS X
• Audio Containers Support: MP3, WMA, WMA, AAC,
OGG, OGA, FLAC, ALAC, others via applications
• Input Voltage: AC 90~250V, 50/60HZ, DC 12V/3A
• Power Consumption: Depends on the
components use (HDD, others)
• Power Consumption in Standby: =< 0.5W
• Storage Temperature: -10~70°C
• Operating temperature: 0~45°C
• Humidity: <95%
• Net Weight: 1,1 kg
6 7 8 10
Product Specifications
