Setup Guide ā P/2 DA4xi and P/2 DA6xi
Installation
The Extron P/2 DA4xi and P/2 DA6xi are
distribution ampliļ¬ers taking one video input
(VGA to QXGA) and distributing it to one
buffered loop-through and three (P/2 DA4xi) or
ļ¬ve (P/2 DA6xi) individually buffered outputs.
To install and operate either unit, follow the steps
below.
Step 1
Ensure all devices are powered off or electrical cables are disconnected.
Step 2
Choose a suitable location and mount the distribution ampliļ¬er on a table, in a
rack, or under a desk.
Step 3
Connect a computer source to the 15-pin HD female input connector of the
distribution ampliļ¬er.
Step 4
Connect four (P/2 DA4xi) or six (P/2 DA6xi) high-resolution display devices to
the 15-pin HD output connectors of the distribution ampliļ¬er.
N Output 1, which is labeled āLocal Monitorā is used for DDC reference.
Step 5
Power on the distribution ampliļ¬er.
Step 6
Power on the displays.
Step 7
Power on the source.
Troubleshooting
If the video output is āsoftā on any display, move the video gain switch on the
rear panel to the up (1V) position.
If no image appears:
Check all the input and output video cables are connected and secure.ā¢ī
Check all devices are receiving power.ā¢ī
If the issue still persists, call the Extron support hotline.ā¢ī
Extron USA - West
Headquarters
+ 6800.63 3.987
I nside USA / Canada Only
+1.71 04.491.150
+1.71 74.491.151 FAX
Extron USA - East
+ 6800 .63 3.987
I nside USA / Canada Only
+1.919.863 .1794
+1.919.863 .1797 FAX
Extron Europe
+80 0.3987.6673
I nside Europe Only
+31.3 5 03.4 3.404
+31.3 5 3.4 3.40 50 FAX
Extron Asia
+80 0.7339.8766
I nside Asia Only
+65.6383.4400
+65.6383.466 4 FA X
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+400 83.8 .156 8
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
68-991-50 A
02 09
