DTP HDMI 230 • Setup Guide
This guide provides quick start instructions for an experienced installer to set up and operate the
Extron DTP HDMI 230 digital video extender. The DTP HDMI 230 transmitter and receiver pair can
extend an HDCP-compliant HDMI signal up to 230 feet (70 m).
Installation
Step 1 — Mounting
Turn off or disconnect all equipment power sources and mount the Tx and Rx units as required.
Step 2 — Connections
a — Connect an HDMI HDMI Input connector (Tx)
cable between this port and the HDMI output port of
the digital video source.
NOTE: See the “ “on the back of this guide for to
LockIt™ Lacing Brackets
securely fasten the input HDMI connector to the transmitter.
b — Connect an unbalanced stereo audio source to this 3.5 mm mini Audio input (Tx)
stereo jack for an analog audio input.
c — To pass serial or infrared data or control signals, such as RS-232 and IR connectors
serial control of a projector, connect the master device to the transmitter and the slave
device to the receiver via the RS-232 and IR captive screw connectors on both units.
d — Connect transmitter DTP Out to receiver DTP In. DTP RJ-45 connectors
Extron recommends that you terminate both cable ends in accordance with the
following specifications, at a minimum:
z zTIA/EIA T 568 B CAT 6A, shielded
z24 AWG, solid conductor
ATTENTION: Do not connect these devices to a computer data or telecommunications
network.
Signal LED — Lights when the unit is receiving a TMDS clock signal on the HDMI input (transmitter) or
any valid signal on the DTP In connector (receiver).
Link LED — Lights when a valid link is established between the units on the DTP cable.
e — Connect a display with an HDMI input for display of the HDMI Output connector (Rx)
transmitted direct digital image.
NOTE: See the “ “on the back of this guide for to LockIt™ Lacing Brackets
securely fasten the output HDMI connector to the receiver.
f — Connect a balanced or unbalanced stereo or mono audio Audio Output connector (Rx)
device to the receiver via the Audio captive screw connector. See the drawing below.
Unbalanced Stereo Output Balanced Stereo Output
Do not tin the wires!
Tip
Ring
Tip
Ring
Slee sve
Tip
No Ground Here
No Ground Here
Tip
Slee sve
L R
L R
ATTENTION: .Connect the sleeves to the ground contact. connect the sleeves to the negative (-) contactsDO NOT
Wire color
White-green
Green
White-orange
White-blue
Orange
White-brown
Brown
Blue
TIA/EIA T
568 B
TP Wires
1 8234567
Pins:
5
Pin
1
2
3
6
7
8
4
Ground
Receive pin on connected unit
Tr
ansmit pin on connected unit
Connected RS-232
and IR Device Pins
Tx/Rx
Pins
Receive pin on connected unit
Tr
ansmit pin on connected unit
RS-232 IR
Tx Rx Tx RxG
L R
AUDIO
OUTPUTS
AUDIO
INPUTS
2
g — Connect an IEC power cord between the included 12 VDC Power connector
power supply and a 100-240 VAC, 50-60 Hz source. Connect the power supply to
either unit as shown at right. Use the included tie-wrap to strap the cord to the
captive screw connector.
NOTE: Only one power supply is required. A single power supply
connected to either unit in the pair powers both units. A power
supply is included with each transmitter.
Operation
After all devices are powered up, the system is fully operational. See the definitions
Rear Panel
R
ear
P
ane
l
Front Panel
F
ront
P
ane
l
POWER
12V
0.6 A MAX
21
of the power indications (shown at right), below:
a —Power LED (front panel)
Amber — The unit is receiving power, either locally or remotely (on the DTP cable).
Green — The unit is powered on and is receiving an active HDMI signal, either on
the HDMI input if a transmitter, or transmitted on the DTP cable if a receiver.
b —Power LED (rear panel)
Amber — The unit is receiving power remotely (on the DTP cable).
Green — The unit is receiving power locally.
If any problems are encountered, verify that the cables are routed and connected properly. If your problems persist, call the
Extron S3 Sales and Technical Support Hotline that is closest to you, at the number shown below.
LockIt™ Lacing Brackets
Use an included LockIt Lacing Bracket to securely fasten an HDMI cable to each device as follows.
1. Plug the HDMI cable into the panel connection.
2. Loosen the HDMI connection mounting screw from the panel enough to allow the LockIt
lacing bracket to be placed over it. The screw does not have to be removed.
3. Place the LockIt lacing bracket on the screw and against the HDMI connector, then tighten the
screw to secure the bracket.
ATTENTION: Do not overtighten the HDMI connector mounting screw. The shield
it fastens to is very thin and can easily be stripped.
4. Loosely place the included tie wrap around the HDMI connector and the LockIt lacing bracket
as shown.
5. While holding the connector securely against the lacing bracket, use pliers or similar tools to
tighten the tie wrap, then remove any excess length.
Power Supply
Output Cord
Ridges
Smooth
Captive
Screw
Connector
3"
16 (5 mm) Max.
SECTION A–A
AA
68-2244-50
Rev A
07 12
3
3
1
2
4
5
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Extron USA - East
+1.714.491.1500 +1.919.850.1000
+1.714.491.1517 FAX +1.919.850.1001 FAX
Extron Europe
+800.3987.6673
(Inside Europe Only)
+31.33.453.4040
+31.33.453.4050 FAX
Extron Asia
+800.7339.8766
(Inside Asia Only)
+65.6383.4400
+65.6383.4664 FAX
Extron Japan
+81.3.3511.7655
+81.3.3511.7656 FAX
Extron China
+4000.398766
Inside China Only
+86.21.3760.1568
+86.21.3760.1566 FAX
Extron Middle East
+971.4.2991800
+971.4.2991880 FAX
Extron Korea
+82.2.3444.1571
+82.2.3444.1575 FAX
Extron India
1800.3070.3777
Inside India Only
+91.80.3055.3777
+91.80.3055.3737 FAX
© 2012 Extron Electronics All rights reserved. www.extron.com
DTP HDMI 230 • Setup Guide (Continued)
