  ‐ ‐ ‐HDV TX1 en GB_V2.5 2/16

Productsheet



ModelHDV‐TX1

ArticulatingSemi‐RigidProbe

ForusewiththeHDV600Borescopeonly



Thank probe. you forpurchasingthis cameraprofessional  Thissheetcoversthewarningand

specifications only.forthe probe Instructions the theregarding usageof HDV600Borescopeare

providedintheBorescopeUserGuide.



Note:ThecameraLEDsbecomewarmwhensetto  maximum intensity



CAUTION:FortheArticulatingProbe,donotoperatethearticulationknobwiththe

probe ain coiledconfiguration.Thiswilldamagethearticulationcontrols!

CAUTION:   Always return the articulationandtensionknobstotheneutralposition

beforeremovingthe the probe from inspectionarea.



Thelabelon            the probe provides the Serial Number and Part Number in the format

shown notbelow.Pleasedo removethislabel;otherwisethewarrantywillbeinvalid.



PartNo. No:TX1F/M/R (flex/macro/rigid) Serial  HDV110001



Warnings



 Do         not bend to a smaller diameter than 10cm (4”)

 Warranty         is invalid if stickers, tags, or labels are removed



ArticulatingProbeDescription

1. Articulation knob

2. Articulationtensionknob

3. Articulatingcamera

4. Extensioncablesockets



1 2 3

ArticulationSetupandOrientation



Thearticulation direction and andorientationmaychangeif istheprobe twisted coiledduring

useorwhenstored.Tore‐orienttheprobe:

1. the Place extended probe on a flatsurface

2. the the position. Set tension“F”knobto leftorreleased 

3. the Set articulationknobtothe thecenterpositionwith RΔandΔL

labelsinthehorizontal position. 

4. the the Manuallyadjust  probe andcamerato zerodegreeposition.

5. the 120° Rotate articulationknobclockwisefor abend.

6. the Ifnecessary,manuallyadjust  probe sothatthecameralaysflat on 

the     surface with a 120° articulation

7. the Rotate articulationknobcounter‐clockwiseandconfirmproper

orientation.



Specifications



Resolution640 480 xpixels

Length1m(3.3’)

Outerdiameter(O.D.)6mm(0.24”)

Focusdistance 2 to 6cm (0.79to2.36”)

Housing Stainless Steel

Field of View(FOV)60º

NumberofLEDs4

LampOutput 20mmmax3500Luxat 

Operating Temperature  ‐20to to70°C ‐ ( 4 158°F)

StorageTemperature ‐20to to70°C ‐ ( 4 158°F)



Thisisproductiswarrantedforoneyear.



Allrightsreservedincludingtherightof orreproductioninwhole in inpart anyform

ISO‐9001Certified

www.extech.com


