Page 1/12

Vanco Part Number:

EVEXHDB1

HDBaseT® Extender

230ft/70m 4K UHD

www.vanco1.com • 800.626.6445

HDBaseT™ EXTENDER

230ft/70m 4K UHD

www.vanco1.com2

1. Do not expose this unit to water, moisture, or

excessive humidity.

2. Do not install or place this unit in a built-in

cabinet, or other conned space without

adequate ventilation.

3. To prevent risk of electrical shock or re

hazard, due to overheating do not obstruct

unit’s ventilation openings.

4. Do not install near any source of heat,

including other units that may produce heat.

5. Do not place unit near ames.

6. Only clean unit with a dry cloth.

7. Unplug unit during lightening storms or when

not used for an extended period of time. A

surge protector is strongly recommended.

8. Protect the power cord from being walked on

or pinched, particularly at the plugs.

9. Use unit only with accessories specied by

the manufacturer.

10. Refer all servicing to qualied personnel.

CAUTION

HDMI is a very complex technology requiring continuous authentication of the signal and the same

video resolution and audio settings on all electronic equipment in the system. When there are multiple

sources and displays, the video resolution and audio setting on all connected units must be adjusted

to correspond with that of the display having the lowest video and audio capability.

WARNING

DEAR CUSTOMER

Thank you for purchasing this product.

For optimum performance and safety, please

read these instructions carefully before connecting, operating or

adjusting this product. Please keep this manual for future reference.

This product is 100% inspected and tested in the United States to verify

HDMI performance parameters.

800.626.6445 3

INTRODUCTION

The Evolution by Vanco EVEXHDB1 HDBaseT Extender over Single Cat5e/6 with RS-232, bi-directional IR, auto EDID/EQ,

and PoC extends 4K/UHD and high denition video and audio with RS-232 and IR signals, and power up to 131ft/40m

over a single Cat5e/6 cable. RS-232 pass-through allows for third party integration or to send control signals to the

connected display. Also features Power over Cable (PoC) Technology, which transmits power over Cat5e/6, allowing either

the Transmitter

or Receiver to be powered without the use of a power supply, you pick and choose which side to power.No EDID or EQ

adjustments are necessary as the units automatically adjust for compatibility and gain. For extending HDMI over a single

Cat5e/6 with RS-232, IR, and PoC, the EVEXHDB1 is a great plug and play solution for extending 4K UHD signals.

The EVEXHDB1 includes two units: transmitting unit (EVEXHDB1-TX) and receiving unit (EVEXHDB1-RX). The transmitting

unit is used to capture the HDMI input with RS-232 and IR signals and carries the signals over a single Cat5e/6 cable. The

receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing RS-232 and IR signals.

FEATURES

HDBaseT™ Extender

Part # EVEXHDB1

• Features HDBaseT™ Technology, optimized for whole-home or commercial distribution of uncompressed

high-denition signals at more than twice the distance of standard HDMI cables without degradation

• HDBaseT Extender can connect uncompressed full HD digital video and audio through a single 230ft/70m

Cat5e/Cat6 cable

• Features Power over Cable (PoC) Technology which transmits power over Cat5e/6, allowing for either

Transmitter or Receiver to be powered without the use of a power supply. The result is an easy and

exible installation with low maintenance.

• Transmission Range: Extends 1080p resolutions up to 230ft (70m) over a single Cat5e/6 cable and

4K@60Hz, 4:2:0 color subsampling up to 131ft (40m)

• Bi-directional IR control

• High Bandwidth: 10.2 Gbps

• HDCP 2.2 compliant

• CEC Support

• Slim and compact design

• Power Supply: DC 12V

• Dimensions: 2.4” W x .9” H x 4.7” D
