EvoHeat Evo Fusion-i Manual
Read below 📖 the manual in Italian for EvoHeat Evo Fusion-i (27 pages) in the Heater category. This guide has been helpful for 5 people and has been rated 4.5 stars on average by 2 users
Page 1/27
info@evoheat.com.au
1300 859 933
www.evoheat.com.au
Fusion-i Series Manual
Page 1
Contents
1. Introduction.................................................................................................................................................................... 2
2. Dimensions.................................................................................................................................................................... 3
3. Quick Start Guide .......................................................................................................................................................... 4
4. Safety Instructions ......................................................................................................................................................... 6
5. Installation ..................................................................................................................................................................... 7
5.1 System Installation .................................................................................................................................................. 7
5.2 Location of Installation ............................................................................................................................................ 7
5.3 Airflow Clearances .................................................................................................................................................. 8
5.4 Adequate Water Flow .............................................................................................................................................. 8
5.5 Rubber Feet ............................................................................................................................................................ 8
5.6 Condensate Drain Barb ........................................................................................................................................... 8
5.7 Drainage & Condensation ....................................................................................................................................... 8
5.8 Plumbing ................................................................................................................................................................. 9
5.9 Electrical Connection .............................................................................................................................................. 9
5.10 Initial Start- 9Up .......................................................................................................................................................
6. Operation..................................................................................................................................................................... 10
6.1 The Controller ....................................................................................................................................................... 10
6.2 Operating Functions .............................................................................................................................................. 11
6.2.1 Startup & Shutdown ....................................................................................................................................... 11
6.2.2 Switching Modes ............................................................................................................................................ 11
6.2.3 Setting the Target Temperature ..................................................................................................................... 11
6.2.4 System Time Settings .................................................................................................................................... 12
6.2.5 Timer Settings ................................................................................................................................................ 12
6.2.6 Silent Settings ................................................................................................................................................ 13
6.2.7 Keyboard Lock ............................................................................................................................................... 14
6.2.8 Fault Interface ................................................................................................................................................ 14
7. Troubleshooting .......................................................................................................................................................... 15
7.1 Electronic Control Fault Table ............................................................................................................................... 15
7.2 Frequency Conversion Board Fault Table ............................................................................................................ 16
8. Appendix ..................................................................................................................................................................... 17
8.1 Wiring Diagrams .................................................................................................................................................... 17
8.2 Parameter List ....................................................................................................................................................... 19
8.3 Refrigerant Saturation Temperature ..................................................................................................................... 19
8.4 Cable Specifications .............................................................................................................................................. 20
8.5 Wi-Fi Module Connection (Optional) ..................................................................................................................... 20
9. Maintenance ................................................................................................................................................................ 21
9.1 F.A.Q ..................................................................................................................................................................... 21
9.2 Advanced .............................................................................................................................................................. 22
10. Warranty .................................................................................................................................................................... 25
info@evoheat.com.au
1300 859 933
www.evoheat.com.au
Fusion-i Series Manual
Page 2
1. I ntroduction
This manual contains information relating to the installation, troubleshooting, and maintenance of this operation,
EvoHeat unit. Instructions in this manual must always be followed. Failure to comply with these recommendations will
invalidate the warranty. Should you have any questions or require technical support, call the EvoHeat office on 1300
859 933 to speak to our team.
The Evo Fusion i heat pump is the ideal choice for recreational pool & spa -
owners looking to extend their swim season with minimal running costs.
Designed with the latest technology including stepless full DC inverter
compressors, fans, and control systems the Evo Fusion i is the energy – -
efficient and environmentally friendly way to enjoy a longer swim season.
TECHNICAL DATA - - - - Fusion i 7 Fusion i 9 Fusion i 12 Fusion i 16 Fusion- i 19
Heat output at 27°C air/26°C water kW 7.24 9.00 11.66 16.00 18.70
Heat output at 15°C air/26°C water kW 5.64 7.00 8.62 12.60 14.00
Cooling output at 35°C air/30°C water kW 3.35 4.22 5.01 8.52 10.21
C.O.P. at 27°C air -12.13 5.66 -12.39 5.84 -12.57 5.84 -10.83 5.50 10.94 5.12 -
Consumed power kW 0.15 1.28- -0.18 1.54 -0.16 2.00 -0.30 2.91 0.32 3.65 -
Power Supply 220-240/1/50
Max current per phase A 6.4 8.4 10.9 16.6 17.5
Connection type 10amp 10amp 15amp hard wired hard wired
Fan quantity 1 1 1 1 1
Fan speed RPM 400- - - - - 700 400 800 400 800 400 750 400 750
Noise at 1M dB(A) 38- - - - - 50 39 51 42 53 43 54 43 55
Noise at 1M in silence mode dB(A) 39 41 43 44 44
Refrigerant gas R32 R32 R32 R32 R32
PVC Water connection mm 40 40 40 40 40
Water flow volume L/min 40 50 60 90 100
Water pressure drop (max) kPa 2 3 4 5 5
Net dimensions L/W/H mm 1004/418/605 1004/418/605 1004/418/605 1046/453/765 1161/490/862
Net weight kg 42 45 46 66 70
*Heating: 27°C ater 26°C / umid 80%*A Wir / H
The data above is based on the Evo heat pump only, it does not include auxiliary devices. Product specification information p above is rovided
correct at the date of printing, this data may change without notice. Please speak with an EvoHeat Specialist for the most current product
specifications.
Product Specifications
| Brand: | EvoHeat |
| Category: | Heater |
| Model: | Evo Fusion-i |
