DOCUMENT CAMERA
Instruction Manual
Please read this instruction manual carefully before using this
product and keep it for future reference.
English - 0
English - 1
Contents
IMPORTANT SAFEGUARDS ............................................................................. 2
BEFORE YOU USE ............................................................................................ 6
1 Package Content .......................................................................................... 8
2 Part names and Functions .......................................................................... 9
2.1 Name of each part ................................................................................. 9
2.2 Functions ............................................................................................. 10
3 Installation and Connections .................................................................... 15
3.1 System diagram................................................................................... 15
3.2 Setting up............................................................................................. 16
3.3 Connecting devices ............................................................................. 17
3.4 Start using the i-Pochette .................................................................... 19
4 Operation Procedure.................................................................................. 20
4.1 Presentation using printed materials, etc. ........................................... 20
4.2 Presentation using the supplied software with the USB-connected PC21
4.3 Presentation using a Microscope. ....................................................... 22
4.4 How to switch image sources .............................................................. 23
4.5 How to zoom in /out of images ............................................................ 23
4.6 How to use the auto focus................................................................... 23
4.7 How to adjust the brightness ............................................................... 23
4.8 How to capture images........................................................................ 23
4.9 How to view captured images..............................................................24
4.10 How to freeze images.......................................................................... 24
4.11 How to delete captured images........................................................... 24
5 Troubleshooting .........................................................................................25
6 Specifications ............................................................................................. 26
English - 2
IMPORTANT SAFEGUARDS
îš„ Read Instructions All the safety and operating instructions should be read
before the appliance is operated.
îš„ Retain Instructions The safety and operating instructions should be retained
for future reference.
îš„ Heed Warnings All warnings on the product and in the operating instructions
should be adhered to.
îš„ Follow Instructions All operating and use instructions should be followed.
îš„ Cleaning Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
îš„ Attachments Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
 Water and Moisture Do not use this product near water – for example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near
a swimming pool, and the like.
îš„ Placement Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturer's instructions,
and should use a mounting accessory recommended by the manufacturer.
îš„ Ventilation Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from overheating,
and these openings must not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other similar
surface. This product should not be placed in a built-in installation such as a
bookcase or rack unless proper ventilation is provided or the manufacturer's
instructions have been adhered to.
îš„ Power Sources This product should be operated only from the type of power
source indicated on the marking label. If you are not sure of the type of power
supply to your home consult your appliance dealer or local power company.
For products intended to operate from battery power, or other sources, refer
to the operating instructions.
îš„ Grounding or Polarization This product may be equipped with either a
