H C 7 5 0 1
I N S T R U C T I O N M A N U A L
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons.
CAUTION
· Do not use any power supply other than
specified.
WARNING
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
* The CAUTION label is attached on the
bottom of camera.
INFORMATION
This equipment has been tested and found
to comply with the limits for Class A digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to
provide reasonable protection against
harmful interference when the equipment
is operated in a commercial environment.
This equipment generates, use, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a
residential area is likely to cause harmful
interference in which case the user will be
required to correct the interference at his
own expense.
USER-INSTALLER CAUTION: Your
authority to operate this FCC verified
equipment could be voided if you make
changes or modifications not expressly
approved by the party responsible for
compliance to Part of the FCC Rules.
- 1 -
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, install in accordance with the
manufacturer's instructions.
8. Do not install near heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
9. Only use attachment/accessories specified by the manufacturer.
10. Unplug this apparatus during lighting storms or when unused for long periods of
time.
11. Refer all servicing to qualified personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged,
liquid has been spilled or objects have been fallen onto the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
- 2 -
PART NAMES AND FUNCTIONS
4
60 (2.4)
3
1
2
2
6
7
9
10
5
8
33 (1.3)
140 (5.5)
33 (1.3)
60 (2.4)
Lens mount
Mount a CS-mount lens. For C-mount lens or C-mount coupler, use supplied C-mount ring.
Camera mount
For mounting a camera on bracket, tripod, etc. (1/4"-20UNC thread)
Back focus dial
Refer to "HOW TO USE" on page 4 for details.
IRIS terminal
Connect when an automatic iris lens is used.
VIDEO OUT terminal
Connect to a monitor TV, etc. (BNC connector)
S-VIDEO OUT terminal
Connect to a VCR with S-video terminal. (MiniDIN4Pjack)
SC-phase adjustment
Adjustment the SC phase of external synchronous control.
Camera control switches
[Display button, Shift button, Select button, Data button (up, down)]
Refer to "CAMERA CONTROLS (OSD)' on page 6.
8
7
6
5
4
3
2
1
All dimensions in mm (inch)
