Indoor/Outdoor Folding-Frame Portable Projection Screen
User’s Guide
Thank you for choosing the portable projection screen! Please read user guide Yard Master Pro 2 this
before utilizing the screen. Correct usage and maintenance will ensure a long product life
Care & Use Instructions
◆ Elite highly recommends two people to assemble the screen.Yard Master Pro 2
◆Dust, dirt and scratches on the projection surface will aect the picture quality, please take note of the
points below to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use ngers or sharp objects to point on the projection surface; this will damage the screen
material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
◆After using the screen, disassemble and store it in the carrying bag provided. it
◆To avoid damage and injury, the screen should only be operated by adults.
Product Description
Design: The aluminum frame is designed to be light weight and easily operated making it easy to carry,
assemble and disassemble.
Projection Screen Surfaces: The screen surface is attached to the rectangular frame and held in place by
snap buttons, which ensure an evenly stretched and at surface. The screen materials are durable and can
be folded many times without causing damage or distortion to the surfaces.
Correct usage of the projection screen will ensure better viewing results.
For front projection ( ), assemble and view the screen as indicated in Fig.1. CineWhite®
For rear projection ( ), assemble and view the screen as indicated in Fig. 2. WraithVeil
Fig. 1
Fig. 2
JA12112018 www.eliteproav.com 2
Hardware and Parts List
A. Folding frame x1
B. Left and right folding legs p2-x
C. Knob Screw (Refer to Chart)
D. Front Projection screen material x1
E. Screen material bag x1
F. Carrying Bag x1
G. Rope p2-x2
H. Eyebolt p2-x2
I. Stake p2-x4
Note: The parts list above is subject to change without notice.
Models
Knob Screw
Max Height
145” (16:9)
10 pcs
133.5 inches
180” (16:9)
10 pcs
159.8 inches
200” (16:9)
14 pcs
149.6 inches
Frame Assembly
1. Take the out of the and place it on a at surface. Fully unfold the folding frame (A) carrying bag (F)
longer sections first, as shown below.
2. Next, unfold the frame until the latch on the hinge “clicks” into place. Repeat the procedure for the
shorter sections, as shown below.
JA12112018 www.eliteproav.com 3
Note: When unfolding the frame and legs, be sure the latches on the hinges "click" into place. Please also
make sure all 4 corners of the frame are at a 90° angle and the hinged support bar is straight and not bent.
Screen Material Attachment
1. Take the out of the and align the corners of the screen screen material (D) screen material bag (E)
material with the inside corners of the frame.
2. Once the screen material is fully extended, secure the material by snapping the buttons onto the frame
studs. Fasten the buttons in the following order as shown on . Fig.1
Note: Snap the buttons on each corner rst, then work your way out to the center on each side.
Fig.1
1
3
2
4
5
6
8
7
