Zx1 Series

Loudspeaker

Owner’s Manual

Electro-Voice Zx1 Series Owner’s Manual

Important Safety Instructions

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliﬁers) that

produce heat.

8. Only use attachments/accessories speciﬁed by the manufacturer.

9. Do not expose this apparatus to dripping or splashing and ensure that no objects ﬁlled with liquids, such as vases, are

placed on this apparatus.

Management of WEEE (waste electrical and electronic equipment) (applicable in Member States of the European

Union and other European countries with individual national policies on the management of WEEE) The symbol on the

product or on its packaging indicates that this product may not be treated as regular household waste, but has to be

disposed through returning it at an Electro-Voice dealer.

The lightning ﬂash with arrowhead symbol, within an equilateral

triangle is intended to alert the user to the presence of

uninsulated “dangerous voltage” within the product’s enclosure

that may be of sufﬁcient magnitude to constitute a risk of

electric shock to persons.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating

and maintenance (servicing) instructions in the literature

accompanying the appliance.

The asterisk within an equilateral triangle is intended to inform

the user to necessary installation or removal instructions

regarding equipment or hardware use relating to the system.

WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC

SHOCK, DO NOT EXPOSE THIS APPLIANCE TO

RAIN OR MOISTURE.

AVIS: RISQUE DE CHOC ELECTRIQUE. NE PAS OUVRIR.

WARNING: CONNECT ONLY TO MAINS SOCKET WITH

PROTECTIVE EARTHING CONNECTION.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Electro-Voice Zx1 Series Owner’s Manual 3

Precautions

Table Of Contents

Description 4 ..............................................................................................................................................................

System Features..................................................................................................................................................... 4

Speciﬁcations 5 .........................................................................................................................................................

Tripod and Floor Monitor Operation 6 ..................................................................................................................

Suspending Zx1 Loudspeakers 8 ..........................................................................................................................

Rotating the 90° Horn 9 ..........................................................................................................................................

Rotating the Logo 9 ..................................................................................................................................................

Recommended Conﬁgurations ......................................................................................................................... 10

Dimensions 12 ............................................................................................................................................................

Frequency Response Graphs 13 ...........................................................................................................................

Zx1 Model Reference Table 13 ...............................................................................................................................

Troubleshooting 14 ....................................................................................................................................................

• Do not use Zx1 loudspeakers in an environment where temperatures exceed +40°C (104°F).

• Never expose a Zx1 loudspeaker to rain, water, or high moisture.

• Electro-Voice Zx1 loudspeakers are easily capable of generating sound pressure levels sufficient

to cause permanent hearing damage to anyone within normal coverage distance. Caution

should be taken to avoid prolonged exposure to sound pressure levels exceeding 90 dB.
