Elba EIC-C2019(BK) Manual
Read below 📖 the manual in Italian for Elba EIC-C2019(BK) (5 pages) in the Oven category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users
Page 1/5
Please read this manual carefully before
operating your set．
Retain it for future reference.
Record modeI number and serial number
of the set．
See the label attached on the set
and quote this information to your dealer
when you require service．
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate.
INDUCTION COOKER
MODEL : EIC-C2019(BK)
Owner’s Manual
IMPORTANT SAFEGUARDS
1. Read all instructions before using.
2. Do not dismantle and refit parts or repair the appliance on your own.
3. Do not contact the plug with wet hands.
4. Do not let the power cord remains plugged when not in use.
5. Do not use the appliance when the power cord is damaged or the plug is not
properly inserted.
6. Never bend or bind the power cord or apply by excessive force, otherwise it
may cause damage. If power cord is damaged, it must be replaced by the
manufacturer or its service center or a similarly qualified person in order to
avoid hazards.
7. Place the appliance on a stable surface.
8. Never use the appliance where it is likely to subject to damp or close to fire.
9. Never rinse the appliance directly with water to avoid damaging the
appliance.
10. Never use the appliance at the place where it can be reached by children.
11. Do not cook without load or overload of food. Otherwise it will cause
deformation of the pot and appliance.
12. Metallic objects such as knife, forks, spoons, lids should not be placed on the
cooking plate as it may conduct heat and get hot.
13. Do not carry the appliance during operation.
14. Do not drop objects onto the cooking plate , in case it cracks, immediately
turn off the power supply and unplug the plug from the power socket and
send it for repair.
15. The content of the food loaded in the pot should not be exceeding 4 kg;
otherwise it will cause damage and malfunction of the appliance.
16. After cooking, high heat temperature that produced from the pot will
conduct onto the appliance, NEVER touch the cooking plate immediately
after used.
17. When using high frequency, noise will be heard as it is the result of the metal
materials of pot , it is not malfunction. While operating the appliance, the
running sound of fan will be heard as the fan will rotate for quite sometimes
to reduce the inner heat.
18. Do not place a sheet of paper between the pot and the cooking plate. The
paper may get burnt!
19. Do not place the appliance near objects which will be affected by magnet;
such as: radios, televisions, automatic-banking cards and cassette tapes.
20. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliances by a person responsible for their safety.
21. Children should be supervised to ensure that they do not play with the
appliance.
22. This appliance is intended to be used in household and similar applications.
23. The appliance is not intended to be operated by means of an external timer
or separate remote-control system.
24. Save these instructions for future reference.
Black Crystal Glass
Air Outlet
Control Panel
Air Inlet
PRODUCT DESCRIPTION
CONTROL PANEL
Cooking plate
1 2
Power Cord
MANUAL MODES
OPERATING THE APPLIANCE - (MANUAL MODE)
ICONS
ADJUSTABLE
COOKING TIME
(HOUR)
DISPLAY
INDICATIONS
FUNCTIONS
POWER (WATT)/
TEMPERATURE
O
( C) RANGE
ADJUSTABLE
COOKING TIME
(MINUTE)
300-2000W 1-59 Up to 23 hours Power level
Up to 23 hours1-59
TemperatureUp to 23 hours
1-59
o
60-240 C
Stir fry
Roast TemperatureUp to 23 hours
1-59
3 4
Hot Pot
Fry
o
60-240 C
o
60-240 C
Temperature
1 Place the appliance pot at the centre of the cooking plate. Warning: Please．
do not power on the appliance with an empty pot as this will cause damage and
deformation to the pot. Power on the appliance and you will hear a “beeping”
sound. The display screen will show “----”.
2 Touch the “ON/OFF” icon and then followed by the cooking function icon ．
to select require cooking functions.
3 Touch the cooking function icon, the red light indicator for “HOT POT” will ．
light up. The display screen will show 1400. The default operating power level is at
1400W. The power level can be adjusted by touching the “+” or “-” icon.
Note: Press “+” icon to increase the power level and press “-” icon to reduce the
power level.
4 Continue to touch the cooking function icon, the red light indicator for ．
“STIR- FRY” will light up. The display screen will show 240C. The default operating
touching the “+” or “-” icon.
Note: Press “+” icon to increase the temperature level and press “-” icon to reduce
the temperature level.
5 Continue to touch the cooking function icon, the red light indicator for “FRY” ．
will light up. The display screen will show 220C. The default operating
touching the “+” or “-” icon.
Note: Press “+” icon to increase the temperature level and press “-” icon to reduce
the temperature level.
6 Continue to touch the cooking function icon, the red light indicator for ．
“ROAST” will light up. The display screen will show 180C. The default operating
temperature level is at 180 C. The temperature level can be adjusted by
touching the “+” or “-” icon.
Note: Press “+” icon to increase the temperature level and press “-” icon to reduce
the temperature level.
7 To cancel any of the selected cooking function, touch the “ON/OFF” icon. ．
8 After cooking has finished, power off the appliance and unplug the ．
appliance.
PRE- SET MODES
Water
Steam
Soup
Milk
2000W
2000W
2000W
500W AU
FUNCTIONS DISPLAY INDICATIONS
(AU AUTOMATIC)=
POWER (WATT)/
TEMPE RATURE
O
( C) RANGE
AU
AU
AU
ICONS
1 Place the appliance pot at the center of the cooking plate. Warning: Please．
do not power on the appliance with an empty pot as this will cause damage and
deformation to the pot. Power on the appliance and you will hear a “beeping”
sound. The display screen will show “----”.
2 Touch the “ON/OFF” icon and then followed by the cooking function icon ．
3 Touch the cooking function icon until the red light indicator for “WATER” ．
lights up. The display screen will show “AU”. At this mode, you cannot select the
power level by touching the “+” or “-” icon. The water mode allows you to boil
water in a fast way. The suggested boiling time for 1 liter is 3-4 minutes, for 2-3
liters is 9-15 minutes.
Note: The boiling time may be vary depending on the purity of water and surrounding
pressure.
4 Continue to touch the cooking function icon until the red light indicator for ．
“STEAM” lights up. The display screen will show “AU”. At this mode, you cannot
select the power level by touching the “+” or “-” icon. The steam mode allows you
to steam various types of food, such as steamed ribs or chicken.
5 Continue to touch the cooking function icon until the red light indicator for ．
“SOUP” lights up. The display screen will show “AU”. At this mode, you cannot
select the power level by touching the “+” or “-” icon.
6 Continue to touch the cooking function icon until the red light indicator for ．
“MILK” lights up. The display screen will show “AU”. At this mode, you cannot select
the power level by touching the “+” or “-” icon. While operating, the appliance will
turn into on and off mode automatically to maintain the temperature. It is to make
sure the milk is cooked evenly.
7 To cancel any of the selected cooking function, touch the “ON/OFF” icon. ．
8 After cooking, power off the appliance and unplug the appliance. ．
OPERATING THE APPLIANCE (PRE-SET MODES)
VOLTAGE ICON
1 While operating the appliance, you can always check the power level by ．
touching the “VOLTAGE” icon.
2． For example, while using the “HOT POT” cooking function, after selecting the
to select require cooking functions.
temperature level is at 240 C. The temperature level can be adjusted by
temperature level is at 220 C. The temperature level can be adjusted by
Product Specifications
| Brand: | Elba |
| Category: | Oven |
| Model: | EIC-C2019(BK) |
