Page 1/1
Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\1544121_01018.doc
Erstelldatum/create date: 26.08.2008 15:17:00Aktualisiert/up dated: 22.01.2009
As special accessories available
:
Automatic welding shield Art.-No.: 15.842.50
TIG welding torch kit Art.-No.: 15.441.30
9 - 13 Bar code: 4006825 547191 Bar code: 4006825 549911
Steel wire brush Art.-No.: 15.934.00
Rod electrode Art.-No.: 15.917.38
Bar code: 4006825 156904 Ø 2 x 300 mm, 200 pcs Bar code: 4006825 506334
Metal slag hammer Art.-No.: 15.841.10 Rod electrode Art.-No.: 15.917.39
Bar code: 4006825 152210 Ø 2.5 x 350 mm, 175 pcs Bar code: 4006825 506341
1
2
4
3
BT-IW 160
Inverter Welding Machine
Art.-No. 15.441.21
Features
Fan cooling
Carrying belt (1)
Gas outlet for WIG equipment (2)
Electrode holder (3)
Earth terminal (4)
This arc welding unit is powerful and also mobile ideally suitable due to modern inverter technology. Low weight and
compact dimensions aord this. The integrated cooling fan cares for a high power-on time. With the separate available
TIG equipment you can also weld with TIG method.
Technical Data
Mains: 230 V ~ 50 Hz
Fuse: 16 A
Welding current
(coated rod electrode): 20 - 150 A
Welding current
(TIG-Welding): 20 - 160 A
Idle voltage: 80 V
Electrodes-Ø: 1.6 – 4.0 mm
Power-on time
(coated rod electrode): 25 % at 150 A / 60 % at 105 A /
100 % at 20 A
Power-on time
(TIG-Welding): 25 % at 160 A / 60 % at 103 A /
100 % at 80 A
Net weight: 11.5 kg
Gross weight: 12.5 kg
Packing dimensions: 505 x 350 x 270 mm
Bar code: 4006825 549898
Sales unit: 1 pc
Product Specifications
| Brand: | Einhell |
| Category: | Welding machine |
| Model: | BT-IW 160 |
