Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\3417060_01016.doc
Erstelldatum/create date: 13.04.2006 09:12:00Aktualisiert/up dated: 05.02.2009
Petrol Snow Thrower
Art.-No.: 34.170.60
BSF 55
Bar code: 4006825530698
Sales unit: 1 pc
As special accessory available:
Snow Chains SK 1 Art.-No.: 34.170.80
Bar code: 4006825532722
Features
:
- Clutch lever for milling drive (1)
- 7-gear-switching (2)
- Adjustable cover for controllable throwing range (3)
- Snow ejection unit (4)
- Robust milling unit (5)
- Adjustable Slide vats (6)
- Air-î‹‹lled, abrasive proî‹‹le winter tyres (7)
- Powerful 4 stroke engine (8)
- Oil deficiency safety (9)
- Ergonomically handle (10)
- Clutch lever for traction drive (11)
- Independent coupling for wheels and miller
- Optionally 1 wheel or 2 wheel drive
- Full crank shaft
Technical data
:
- Engine: 1-cylinder, 4-stroke engine
4 kW / 5.5 HP
- Engine displacement: 163 cm
3
- Operating speed: approx. 3000 rpm
- Starting system: Linkage to start the motor
- Speed (max.): 4 km/h
- Gear forwards: 5
- Gear backwards: 2
- Fuel: normal petrol (lead-free)
- Tank capacity: 3.6 litres
- Motor oil quantity: 0.6 litres (10W30)
- Working width: 56 cm
- Snow height (max.): 510 mm
- Throwing range (max).: 10 – 15 m
- Working area: approx. 1400 m
2
/h
- Working capacity: approx. 350 cm
3
/h
- Ejection bracket adjustment: 190°
- Net weight: 74.3 kg
- Gross weight: 85 kg
- Packing dimensions: 900 x 620 x 680 mm
The powerful, self propel Petrol Snow Thrower
with high quality 4 stroke engine (4 KW / 5.5 HP) warrants
for a
quiet running, economy, high power reserve and long life span.
It’s suitable with the 5 forwards and 2 backwards gears and the snow ejection adjustable by means of adjustment
crank about 190° for professional milling of snow surfaces of quite different nature. Due to the throwing range of 10-
15m large areas can be eortlessly made free from snow. With the driven wheels, the ergonomically push bracket
and the skids it’s easy to move through the snow.
Depending on application the tool can be in a few handles from 2-wheel-drive to a 1-wheel-drive undergo
reconstruction.
1
2 3
4
6
7
8
9
10
11
5
2
