Page 1/20
DTSU666 series three phase four wire electronic energy meter (Din-rail)
DSSU666 series three phase three wire electronic energy meter (Din-rail)
Manual
ZTY0.464.1002
Zhejiang Chint Instrument & Meter Co., Ltd.
June , 2019
Catalog
1. Brief Introduction ............................................................................................................................. 1
2. Working Principle ............................................................................................................................. 2
3. Main Technical Performance & Parameters ..................................................................................... 3
4. Main function .................................................................................................................................... 6
5. Outline and installation size ............................................................................................................ 12
6. Installation and operation manual ................................................................................................... 13
7. Diagnosis, analysis and elimination for common faults ................................................................. 16
8. Transportation & Storage ................................................................................................................ 17
9. Maintenance & Service ................................................................................................................... 17
DTSU666 series and DSSU666 series three phase electronic
energy meter(DIN-Rail)
ZTY0.464.1002
Operation manual
Page 1, Total 18
1. Brief Introduction
1.1. Main application & applicable range
DTSU666 series three phase four wire and DSSU666 series three phase three wire electronic
energy meter (din-rail) (hereinafter referred to as the “instrument”) is designed based on power
monitoring and energy metering demands for electric power system, communication industry,
construction industry, etc. as a new generation of intelligent instrument combining measurement and
communication function, mainly applied into the measurement and display for the electric parameters
in the electric circuit including three voltage, three current, active power, reactive power, frequency,
positive& negative energy, four-quadrant energy, etc. Adopting the standard DIN35mm din rail
mounting and modular design, it is characterized with small volume, easy installation and easy
networking, widely applied into the internal energy monitoring and assessment for industrial and
mining enterprises, hotels, schools, large public buildings.
Complied standards:
IEC 61010-1:2010 Safety requirements for electrical equipment for measurement control and 《 ,
laboratory use Part1:General requirements 》
IEC 61326-1:2013 Electrical equipment for measurement control and laboratory use EMC 《 , –
requirements Part1:General requirements》
1.2. Product Features
1) Characterized with positive and reverse active power, combined active power, combined
reactive power, four quadrant reactive power metering and storage function with combination mode
character can be set.

Product Specifications

Brand: Deye
Category: Not categorized
Model: CHNTDTSU666
