DeWalt DXPW3835 Manual
DeWalt
High pressure cleaner
DXPW3835
Read below 📖 the manual in Italian for DeWalt DXPW3835 (68 pages) in the High pressure cleaner category. This guide has been helpful for 5 people and has been rated 4.5 stars on average by 2 users
Page 1/68
DXPW3835
Pressure Washer
Laveuse à pression
Lavadora a presión
INSTRUCTION MANUAL
GUIDE D'UTILISATION
MANUAL DE INSTRUCCIONES
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE
GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE
USAR EL PRODUCTO.
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-877-FNA-GAS1 (1-877-362-4271)•www.dewaltpw.com
2
English
A. Panel assembly
B. Nozzle holder
C. Professional Spray gun
D. Wheel
E. Quick-connect
spray wand
F. Frame
G. Engine dipstick/oil plug
H. Engine switch
I. Starter grip
J. Engine
K. Throttle control lever
L. Choke control
M. Fuel valve lever
N. Gas cap
O. Handle assembly
P. High-pressure hose
Q. High-pressure pump
R. Top handle
DXPW3835 Pressure Washer
Engine
Refer to the engine instruction manual for location and
operation of other engine controls.
Pump
For best results, pump oil designed specifically for
pressure washers is recommended, as these contain a
rust inhibitor and an anti-foaming agent. If this oil is not
available, an SAE 30W non-detergent oil may be used.
H
G
K
L
M
I
FIG. 1
J
C
E
AB
Q
N
D
F
O
P
R
3
English
Definitions: Safety Guidelines
The definitions below describe the level of severity for each
signal word. Please read the manual and pay attention to these
symbols.
DANGER: Indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which,
if not avoided, result in may minor or moderate injury.
NOTICE: Indicates a practice not related to personal injury
which, if not avoided, may result in property damage.
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT THIS
CONTACT US AT: www.dewaltpw.com or 1-877-FNA-GAS1
(1-877-362-4271)
Specifications
MODEL WEIGHT HEIGHT WIDTH LENGTH PSI** GPM** ENGINE
DXPW3835 125 lbs
(56.7 kg)
28"
(71.1 cm)
24"
(60.7 cm)
38"
(96.5 cm)
3800
(26,200 kPa)
3.5
(13.2 L/min)
HONDA GX270***
270 cc OHV
** PSI and GPM ratings determined in accordance with the Pressure Washers Manufacturers Association (PWMA)
standard PW101.
*** HONDA™ is a registered trademarks of the HONDA MOTOR CO., LTD used under license from AMERICAN HONDA MOTOR CO. INC.
Important Safety Instructions
DANGER: Carbon Monoxide. Using an engine indoors can kill
you in minutes. Engine exhaust contains high levels of carbon
monoxide (CO), a poisonous gas you cannot see or smell. You
may be breathing CO even if you do not smell engine exhaust.
WARNING: This product and its exhaust contain chemicals
known to the State of California to cause cancer, and birth
defects and other reproductive harm.
• NEVER use an engine inside homes, garages, crawlspaces or
other partly enclosed areas. Deadly levels of carbon monoxide can
build up in these areas. Using a fan or opening windows and doors
does supply enough fresh air. NOT
• ONLY use outdoors and far away from open windows, doors and
vents. These openings can pull in engine exhaust.
• Even when the engine is used correctly, CO may leak into your
home. ALWAYS use a battery-powered or battery backup CO
alarm in your house. Read and follow all directions for CO
alarm before using. If you feel sick, dizzy or weak at anytime,
move to fresh air immediately. See a doctor. You could have
carbon monoxide poisoning.
Product Specifications
| Brand: | DeWalt |
| Category: | High pressure cleaner |
| Model: | DXPW3835 |
