DeWalt DCBL777 Manual
DeWalt
Leaf blower
DCBL777
Read below 📖 the manual in Italian for DeWalt DCBL777 (36 pages) in the Leaf blower category. This guide has been helpful for 8 people and has been rated 4.5 stars on average by 2 users
Page 1/36
If you have questions or comments, contact us.
Pour toute question ou tout commentaire, nous contacter.
Si tiene dudas o comentarios, contáctenos.
1-800-4-D WALTe
DCBL777
60V Max* Lithium Handheld Blower
Souffleur portatif au lithium-ion de 60V max.*
Soplador de mano con baterÃa de iones de litio de 60V Máx*
Instruction Manual
Guide D’utilisation
Manual de instrucciones
English (original instructions) 4
Français (traduction de la notice d’instructions originale) 12
Español (traducido de las instrucciones originales) 22
1
Fig. A
DCBL777
1 Trigger switch
2 Handle
3 Speed lock button
4 Power head
5 Blower tube
6 State of charge indicator
7 Speed indicator
8 Speed button
9 Tip lock
10 Broom tip
11 Concentrator tip
12 Locking tab
13 Shoulder strap mount
14 Shoulder strap
15 Battery pack
16 Battery release button
5
9
15
11
14
10
16
4
13
1
3
2
7
8
6
12
1 Interrupteur à gâchette
2 Poignée
3 Bouton de verrouillage de la vitesse
4 Ploc moteur
5 Tube de soufflage
6 État du voyant de charge
7 Indicateur de vitesse
8 Bouton de vitesse
9 Verrouillage de l’embout
10 Embout de balai
11 Embout de concentrateur
12 Languette de verrouillage
13 Support de courroie d’épaule
14 Courroie d’épaule
15 Bloc-piles
16 Bouton de libération du bloc-piles
1 Interruptor de gatillo
2 Manija
3 Botón de bloqueo de velocidad
4 Cabezal de potencia
5 Tubo de soplador
6 Indicador de estado de carga
7 Indicador de velocidad
8 Botón de velocidad
9 Bloqueo de punta
10 Punta de escoba
11 Punta de concentrador
12 Lengüeta de bloqueo
13 Montaje de correa de hombro
14 Correa de hombro
15 Paquete de baterÃa
16 Botón de liberación de baterÃa
Product Specifications
| Brand: | DeWalt |
| Category: | Leaf blower |
| Model: | DCBL777 |
