Deaf Bonce Machete MW-80 Manual

Deaf Bonce Speaker Machete MW-80

Read below šŸ“– the manual in Italian for Deaf Bonce Machete MW-80 (16 pages) in the Speaker category. This guide has been helpful for 12 people and has been rated 4.5 stars on average by 2 users

Page 1/16
Machete series
U S E R ā€™ S M A N U A L
M
M
M
MM I
I
I
II D
D
D
DD -
-
-
-- B
B
B
BB A
A
A
AA S
S
S
SS S S
S S
S S
S SS S P
P
P
PP E
E
E
EE A
A
A
AA K
K
K
KK E
E
E
EE R
R
R
RR S
S
S
SS
MW-80
http://deafbonce.com
1. Introduction.
2. Safety instructions.
3. Wiring diagrams.
4. Filtering, recommended ampliļ¬er settings.
5. Speciļ¬cations.
6. Dimensions.
7. Box contents.
8. Warranty and maintenance info.
9. Information on disposal of the electrical and electronic
equipment (for the European countries with separate waste
collection).
2
C O N T E N T S EN
1 . I N T R O D U C T I O N
1. Fasten the audio system properly when installing it in the vehicle. If the component is disconnected during driving, it may
cause serious damage to the passengers of the car or another vehicle.
2. Before installing the components, if possible store the product in the original package to avoid accidental demage to the
product.
3. Be careful when installing and dismantling the speaker systems! Do not let the speaker drop to avoid damage of its moving
parts.
4. When working with tools follow safety rules.
5. Before the installation switch oļ¬€ the head unit and all other audio devices to avoid their damage.
6. Make sure that the location of the audio system does not hinder the proper operation of mechanical and electrical devices
of the vehicle.
7. Do not install components in places exposed to water, excessive humidity, high or low temperature, dust or dirt.
ATTENTION!!! The product may be operated at +5 to +40 Ā°C. In case of moisture condensation, allow the product to dry.
8. When drilling or cutting out holes in the body of the car, make sure that there are no cables or any other important
construction elements under a selected area or inside it.
9. When stretching the speaker cables make sure that they are not in contact with sharp edges or moving mechanical devices.
Make sure that they are ļ¬rmly ļ¬xed and protected over the entire length.
10. The diameter of the speaker cables must be selected in accordance with the length and applied power.
11. Never stretch the cables outside of the car and near the moving parts of the car. This can lead to destruction of the
insulating layer, short circuit and ļ¬re.
12. To protect the cables use rubber gaskets if the wire passes through a hole in the plate, or other similar materials if it lies
close to the parts exposed to heat.
13. Possible commutation versions are presented on the following pages. Using the data from the diagram below, check the
minimum resistance and the connection speciļ¬ed by the manufacturer of your ampliļ¬er. Do not expose the ampliļ¬er to loads
below the predetermined value.
CAUTION!!! High sound pressure can damage your health!
Please use the common sense when controlling volume!
2 . S A F E T Y I N S T R U C T I O N S
3 . W I R I N G D I A G R A M S
4 Ohm 8 Ohm
Voice coil Total impedance
S E R I A L C O N N E C T I O N O F T H E S P E A K E R S
3
EN
Use these diagrams to calculate the resistance of diļ¬€erent connection types.
Thank you for purchasing this Deaf Bonce product of Machete series! Our company is committed to the creation of extremely
high-proļ¬le systems with no loss of quality.
To ensure proper use, please carefully read through this manual before using this product. It is especially important that you
read and observe cautionā€™s in this manual. Please keep the manual in a safe and accessible place for future reference.
