PM- 160
Highlite International B.V. Vestastraat 2 6468 EX Kerkrade the Netherlands – – – –
Ordercode: D6191
MANUAL
ENGLISH
1
PM-160
Ordercode: D6191
Warning
Every person involved with the installation, operation and maintenance of this system has to:
ï‚· be qualified
ï‚· follow the instructions of this manual
Only use the supplied DAP audio adapter.
Your shipment includes:
ï‚· PM- (Announcement microphone) 160
ï‚· AC power adapter
 Jack Jack Unbalanced cable –
ï‚· User manual
Description
The PM-160 announcement microphone is designed to be connected directly to a amplifier input ore a
mixer input. The unit features a clear sound and low feedback sensibility.
ï‚· Mic- volume adjustable on backside
ï‚· Chime volume adjustable on backside
ï‚· Talk button on upside
ï‚· Build-in four tone Chime
Operation
Push down the talk button The light inside the button blinks and a chime sound is send to the output. .
When the light burns continuously, the microphone can be used.
Pressing the button once again, the light blinks and a chime sound is send to the output. The microphone
is now turned off.
Microphone neck LED lights up represent you can speak with microphone, Microphone neck LED lights
off represent microphone is turned off.
CAUTION!
Keep this device away from rain and moisture!
2
PM-160
Ordercode: D6191
Overview
Microphone
Broadcasting speak microphone
Talk
Broadcasting switch control button
DC Input
This connector is used to connect the supplied AC adapter.
Chime volume
Adjust volume of prelude musical
Mic. Volume
Adjust volume of microphone
Balanced out
Balanced output socket
Unbalanced Out
Unbalanced output socket
Specifications
Microphone unit:
Condenser
Freq response:
22 Hz 23 KHz –
Sensitivity:
29dB @ 1kHz
Balanced output:
230mV
Unbalanced output:
110mV
Dimensions:
132x155x380mm
Weight:
0,7Kg
