Read below š the manual in Italian for Daikin VRVIII (24 pages) in the Air conditioning category. This guide has been helpful for 7 people and has been rated 4.5 stars on average by 2 users
Page 1/24
VRVIII system indoor unit
OPERATION MANUAL
HXHD125A7V1B
system indoor unit
Operation manual
1
HXHD125A7V1B
VRVIII system indoor unit
4PW62585-1 ā 11.2010
CONTENTS Page
1. Deļ¬nitions.................................................................................. 1
1.1. Meaning of warnings and symbols................................................. 1
1.2. Meaning of used terms .................................................................. 1
2. General safety precautions........................................................ 2
3. Introduction................................................................................ 2
3.1. General information........................................................................ 2
3.2. Scope of this manual ..................................................................... 2
4. Quick start-up of the unit ........................................................... 3
Space heating operation ................................................................ 3
Domestic water heating operation.................................................. 3
5. Operation of the unit .................................................................. 4
5.1. Remote controller buttons and icons.............................................. 4
5.2. Setting the clock............................................................................. 5
5.3. Space heating operation ( ).......................................................... 6h
Room temperature control ............................................................. 6
Leaving water temperature control................................................. 7
5.4. Domestic water heating operation ( ).......................................... 8w
Automatic storage .......................................................................... 8
Manual storage .............................................................................. 9
Reheat ......................................................................................... 10
Disinfection operation................................................................... 10
5.5. Other operation modes ................................................................ 10
Start up operation ( ) ........................................................... 10d
Defrost operation ( ) ............................................................ 10d
Quiet mode operation ( ) .......................................................... 10s
5.6. Simultaneous demand of space heating and domestic water
heating ......................................................................................... 11
5.7. Temperature read-out mode......................................................... 11
5.8. Schedule timer operation............................................................. 11
Space heating .............................................................................. 11
Domestic water heating................................................................ 13
Quiet mode .................................................................................. 13
5.9. Programming and consulting the schedule timer......................... 13
Programming space heating........................................................ 14
Programming domestic water heating.......................................... 15
Programming quiet mode............................................................. 16
Consulting programmed actions .................................................. 17
Tips and tricks.............................................................................. 17
5.10. Operating the remote alarm option .............................................. 17
5.11. Operating the optional remote controller...................................... 17
5.12. Field settings................................................................................ 18
Procedure .................................................................................... 18
5.13. Field settings table ....................................................................... 19
6. Maintenance............................................................................ 21
6.1. Maintenance activities.................................................................. 21
6.2. Important information regarding the refrigerant used .................. 21
7. Troubleshooting ....................................................................... 21
Thank you for purchasing this unit.
The original instructions are written in English. All other languages
are translations of the original instructions.
This appliance is not intended for use by persons, including children,
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person
responsible for their safety.
Children shall be supervised to ensure that they do not play with the
appliance.
1. DEFINITIONS
1.1. Meaning of warnings and symbols
Warnings in this manual are classiļ¬ed according to their severity and
probability of occurrence.
Some types of danger are represented by special symbols:
1.2. Meaning of used terms
Installation manual:
Instruction manual speciļ¬ed for a certain product or application,
explaining how to install, conļ¬gure and maintain it.
Operation manual:
Instruction manual speciļ¬ed for a certain product or application,
explaining how to operate it.
Maintenance instructions:
Instruction manual speciļ¬ed for a certain product or application,
which explains (if relevant) how to install, conļ¬gure, operate and/or
maintain the product or application.
Dealer:
Sales distributor for products as per the subject of this manual.
Installer:
Technical skilled person who is qualiļ¬ed to install products as per the
subject of this manual.
HXHD125A7V1B VRVIII system indoor unit Operation manual
CAREFULLY READ THESE INSTRUCTIONS BEFORE
OPERATING THE UNIT. THEY WILL TELL YOU HOW TO
USE THE UNIT PROPERLY. KEEP THIS MANUAL IN A
HANDY PLACE FOR FUTURE REFERENCE.
CAUTION
ā This unit contains electrical and hot parts.
ā Before operating the unit, be sure the installation has
been carried out correctly by an installer.
If you feel unsure about operation, contact your
installer for advice and information.
DANGER
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury. It may also
be used to alert against unsafe practices.
NOTICE
Indicates situations that may result in equipment or
property-damage accidents only.
INFORMATION
This symbol identiļ¬es useful tips or additional information.
Electric current.
Danger of burning and scalding.
HXHD125A7V1B
VRVIII system indoor unit
4PW62585-1 ā 11.2010
Operation manual
2
User:
Person who is owner of the product and/or operates the product.
Service company:
Qualiļ¬ed company which can perform or coordinate the required
service to the unit.
Applicable legislation:
All international, European, national and local directives, laws,
regulations and/or codes which are relevant and applicable for a
certain product or domain.
Accessories:
Equipment which is delivered with the unit and which needs to be
installed according to instructions in the documentation.
Optional equipment:
Equipment which can optionally be combined to the products as per
the subject of this manual.
Field supply:
Equipment which needs to be installed according to instructions in
this manual, but which are not supplied by Daikin.
2. G ENERAL SAFETY PRECAUTIONS
The precautions listed here are divided into the following four types.
They all cover very important topics, so be sure to follow them
carefully.
3. INTRODUCTION
3.1. General information
The unit is the indoor part of the air to water REYAQ heat pump. The
unit is designed for ļ¬oor standing indoor installation and used for
heating applications. The unit can be combined with space heating
radiators (ļ¬eld supply) and with an EKHTS200/260AC domestic hot
water tank (option).
A remote controller with room thermostat functionality is standard
supplied with this unit to control your installation.
Refer to the installation manual for the list of options.
3.2. Scope of this manual
This manual describes how to start up and switch off the unit, set
parameters and conļ¬gure the schedule timer by means of the
controller, maintain the unit and solve operational problems.
DANGER: ELECTRICAL SHOCK
Switch off all power supply before removing the switchbox
service panel or before making any connections or
touching electrical parts.
Do not touch any switch with wet ļ¬ngers. Touching a switch
with wet ļ¬ngers can cause electrical shock. Before
touching electrical parts, turn off all applicable power
supply.
To avoid electric shock, be sure to disconnect the power
supply 1 minute or more before servicing the electrical
parts. Even after 1 minute, always measure the voltage at
the terminals of main circuit capacitors or electrical parts
and, before touching, be sure that those voltages are
50 V DC or less.
When service panels are removed, live parts can easily be
touched by accident. Never leave the unit unattended
during installation or servicing when the service panel is
removed.
DANGER: DO NOT TOUCH PIPING AND INTERNAL
PARTS
Do not touch the refrigerant piping, water piping or internal
parts during and immediately after operation. The piping
and internal parts may be hot or cold depending on the
working condition of the unit.
Your hand may suffer burns or frostbite if you touch the
piping or internal parts. To avoid injury, give the piping and
internal parts time to return to normal temperature or, if
you must touch them, be sure to wear protective gloves.
NOTICE
An HXHD125 indoor unit can only be connected to an
REYAQ outdoor unit.
INFORMATION
The installation of the indoor unit(s) is described in the
indoor unit installation manual.
Product Specifications
