Page 1/20
INSTRUCTIONS FOR INSTALLATION AND MAINTENANCE
INSTRUCTIONS POUR L’INSTALLATION ET LA MAINTENANCE
INSTRUCCIONES PARA LA INSTALACION Y EL MANTENIMIENTO
JET - JETINOX - JETCOM
EURO - EUROINOX - EUROCOM
K
DP
ENGLISH
1
CONTENTS page
1. GENERAL 1
2. APPLICATIONS 1
3. PUMPED FLUIDS 1
4. TECHNICAL DATA AND RANGE OF USE 1
5. MANAGEMENT 2
5.1. Storage 2
5.2. Transport 2
5.3. Weights 2
6. WARNINGS 2
6.1. Skilled personnel 2
6.2. Safety 2
6.3. Checking motor shaft rotation 2
6.4. Responsibility 2
7. INSTALLATION 3
8. ELECTRICAL CONNECTION 3
9. STARTING UP 4
10. PRECAUTIONS 4
11. MAINTENANCE AND CLEANING 4
12. MODIFICATIONS AND SPARE PARTS 4
12.1 Removal and replacement of the supply cable 4
13. INSTRUCTIONS FOR ADJUSTING THE PRESSURE SWITCH 4
14. TROUBLESHOOTING 5
1. GENERAL
Read this documentation carefully before installation. Installation and functioning
must comply with the safety regulations in the country in which the product is installed. The
entire operation must be carried out in a workmanlike manner.
Failure to comply with the safety regulations not only causes risk to personal safety and
damage to the equipment, but invalidates every right to assistance under guarantee.
2. APPLICATIONS
JET - JETINOX - JETCOM: Self-priming centrifugal jet pumps with excellent suction capacity, even
when gas is present in the water. Particularly suitable for water supply uses and for pressurization in the
home. Suitable for small farming applications, market gardens, gardening, emergencies in the home and
industrial utilities.
EURO - EUROINOX - EUROCOM: Self-priming multistage centrifugal pump with horizontal action,
suitable for domestic or industrial uses, for water supply systems and pressurization. In farming it is ideal for
small irrigation work and for washing tools and machinery. Also suitable for water containing gas. Water is
recycled only during the priming stage, after which the maximum flow is made available for use with
continuous and constant distribution. These qualities allow vast possibilities for use.
K : Single impeller centrifugal pump designed for domestic, civil, industrial and agricultural installations
and for decanting, mixing and irrigating uses.
DP : Self-priming centrifugal pumps for suction at depths of as many as 30 metres with ejector to be fitted in
4" wells or larger. Used for supplying water to farm houses and in small farming applications.
3. PUMPED FLUIDS
The machine has been designed and built for pumping water, free from explosive
substances and solid particles or fibres, with a density of 61,31 lb/ft3 and a
kinematic viscosity of 1,0764ï‚´
ï‚´
ï‚´
ï‚´ï‚´10-5 ft2/s, and chemically non-aggressive liquids.
4. TECHNICAL DATA AND RANGE OF USE
ï€ Supply voltage: 1 X 115/230V 60Hz see electrical data plate
ï€ Absorbed power: see electrical data plate
ï€ Delivery: from 0,4 to 17,2 m3/h
ï€ Head up: to 72 m.
ï€ Pumped liquid: clean, free from solid bodies or abrasive substances, non-aggressive.
ï€ Protection class: F
From 1.7 to 75 gpm
236 ft
