Quick Installation Guide
Driver & Manual:
www.cudy.com/download
Website:
www.cudy.com
Email:
support@cudy.com
Support
For technical support, the user
guide and more information, please
visit:
https://www.cudy.com/support
NEED TECH HELP?
810600214
Specifications
HS105
12V / 1 A
11 W
5 × 2.5 Gbps RJ45 Ports
25 Gbps
18.66 Mpps
8 K
15 KB
Store and forward
100000 hour
0~40°C
-40~75°C
0%~100%, non-condensing
10%~95%, non-condensin
119x85x28mm
Model
Power Input
Max Power Consumption
Ethernet
Switching Capacity
Throughput
MAC Address Table
Jumbo Frame
Transfer Mode
MTBF
Working Temperature
Storage Temperature
Working Humidity
Storage Humidity
Product Size
Support
For technical support, the user guide and more information, please visit:
http://www.cudy.com/support
support@cudy.com
FCC Statements:
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
EU declaration of conformity
Cudy hereby declares that the device is in compliance with the
essential requirements and other relevant provisions of directives
2014/30/EU, 2014/35/EU, 2009/125/EC and 2011/65/EU.The original
EU declaration of conformity may be found at http://www.cudy.com/
Internet
Router
Connection
HS105
Note: Use the power
adapter provided in the
package to power on
the switch.
5 × 2.5 Gbps
RJ45 Ports
Power LED
Power
1 2 3 4 5
HS105
5-Port 2.5Gbps
Multi-Gigabit Switch
Left LED
2.5Gbps
Activity
Right LED
1Gbps
100Mbps
Activity
LED
Name Indication
Power
Left LED
Right LED
Green
(2.5 Gbps Rate)
Green
(1 Gbps Rate)
Yellow
(100 Mbps Rate)
On: Power on
Off: No Power
Steady on: Connected
Flashing: Connected, with active data
transmission
Steady on: Connected
Flashing: Connected, with active data
transmission
Steady on: Connected
Flashing: Connected, with active data
transmission
