Important: Read before use. • Importante: Leer antes de usar.
Scan to
register your
product warranty
Ultra Long Range
Outdoor Fast Ethernet
PoE+ Extender Kit
Instructions
Model 561952 (IPE-ODFE30)
For additional benets:
or go to: register.intellinet-network.com/r/561952
2
This guide presents the basic steps
to set up and operate this device.
For specifications, visit support.intellinet-
network.com/barcode/561952.
Register your product at register.
intellinet-network.com/r/561952 or
scan the QR code on the cover.
Connections
Device Connections
Note: Your needs and setup may vary. Both
Extender units must be used together.
1 Plug a Cat5e/6 Ethernet cable — up
to 100 m long — from your powered
source device (for example, a PoE
injector or switch) into the Output
connector on one extender.
2 Plug a second Cat5e/6 Ethernet
cable — up to 800 m long — from
the on the first extender to Input
the the second extender. Input
3 Plug a third Cat5e/6 Ethernet cable —
up to 100 m long — from the Output
on the second extender to the device
you want to transmit power and data
to (e.g., a PoE network camera).
Cable Connections
Follow these general steps to make
waterproof connections on all cables that
connect to the units. Use a wrench to ensure
tight connections and whenever necessary.
1 Unscrew the Nut from the Body.
2 Loosen the washer and unscrew the Body
from the unit.
3 Remove the Insert from the Body and feed
the cable through the Nut and Body.
Replace the Insert into the Body .
4 Install the cable plug into the port. Screw
on the Body to the unit.
5 Tighten the Body washer to the unit.
6 Tighten the Nut to the Body.
Nut Body
with
washer
Insert
English
Instructions
3
Instructions
Functionality
This extender is designed to work with all IEEE 802.3bt/at/af-compliant devices.
PoE Standard | Maximum Distance | Available Power
The table below shows select information on the power and the data speeds you can
expect to be delivered to your PoE device based on the capabilities of your equipment
and lengths of cable. For a more detailed table, visit the specifications link that is shown
on the previous page of this manual and click the Downloads tab on the product page.
Series 1: IEEE 802.3af (15.4 W) PSE
1
Cable length
between PSE
and extender 1
2
Cable length
between PoE
extenders
3
Cable length
between extender
2 and PD
Power
(W) at
PD
Data Rate
1 m (3 ft.) 400 m (1,312 ft.) 1 m (3 ft.) 10.27 100 Mbps
100 m (328 ft.) 800 m (2,624 ft.) 1 m (3 ft.) 5.21 10 Mbps
100 m (328 ft.) 400 m (1,312 ft.) 100 m (328 ft.) 8.73 100 Mbps
100 m (328 ft.) 800 m (2,624 ft.) 100 m (328 ft.) 4.78 10 Mbps
Series 2: IEEE 802.3at (30 W) PSE
1
Cable length
between PSE
and extender 1
2
Cable length
between PoE
extenders
3
Cable length
between extender
2 and PD
Power
(W) at
PD
Data Rate
1 m (3 ft.) 400 m (1,312 ft.) 1 m (3 ft.) 23.98 100 Mbps
100 m (328 ft.) 800 m (2,624 ft.) 1 m (3 ft.) 13.41 10 Mbps
1 m (3 ft.) 400 m (1,312 ft.) 100 m (328 ft.) 22.1 100 Mbps
100 m (328 ft.) 800 m (2,624 ft.) 100 m (328 ft.) 12.19 10 Mbps
Series 3: IEEE 802.3bt (60 / 90 W) PSE
1
Cable length
between PSE
and extender 1
2
Cable length
between PoE
extenders
3
Cable length
between extender
2 and PD
Power
(W) at
PD
Data Rate
60 W 1 m (3 ft.) 100 m (328 ft.) 1 m (3 ft.) 43.83 100 Mbps
90 W 1 m (3 ft.) 200 m (656 ft.) 1 m (3 ft.) 76.61 100 Mbps
123
English
