Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
1 of 2
- No Dealer programming required.
- Automacally switches to Rear-view when car is in Reverse mode.
- OBD coder for single acvaon included.
PRODUCT FEATURES:
PARTS INCLUDED:
SPECIAL NOTE:
In the event this unit is to be returned for any reason, the customer must “decode” the radio before
doing so to receive a replacement or refund. See instructions below on how to decode the radio.
rev.12032021
RVCFD-79O Kit
INSTALLATION INSTRUCTIONS:
CODING THE RADIO FOR A BACKUP CAMERA
1. Locate the vehicle’s OBD II port usually located under the steering column.
2. Enter the vehicle and CLOSE ALL DOORS.
3. Turn the key to the ON posion.
4. Plug in the OBD coder from the RVCFD-79O kit to the ODB II port.
5. Wait for the OBD coder to nish coding the radio and give a solid GREEN LED. (See chart below)
6. The radio may ash a few me during this process. It can take around 5 seconds to complete the
coding process. If an error occurs, retry the coding procedure.
7. Aer the coding is complete, disconnet the OBD coder and store in a safe place. This OBD coder is
VIN specic and will only work on this vehicle.
In order for the vehicle to recognize the camera and engage it when in reverse gear, the vehicle must be
coded. Use the ODB II coder included in the RVCFD-79O kit.
DECODING THE RADIO
To decode the radio, repeat the steps above.
Crux Interfacing Solutions • Chatsworth, CA 91311
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
2 of 2
Reading the LED color paern:
Flashing LED Coding Vehicle
Solid Green LED Acvated
Solid Red LED Deacvated
Solid Red & Green LED Error
INTERFACE
GREEN LED
RED LED
VEHICLE APPLICATIONS:
2017 - Up Explorer
2016 - 2017 F-150
2018 - 2020 F-150
2016 - Up Focus
2016 - Up Mustang
2017 - Up F-250
2017 - Up F-350
2017 - Up F-450
2017 - Up F-550
8-PIN
(male plug) LED
(indicator)
OBD CODER
FORD
MS-Sync Gen 3 Radio
rev.12032021
