Page 1/3
Series 6, washing machine, front
loader, 9 kg, 1400 rpm
WGG24409AU
WMZ2200 Floor securing component
WMZ2381 Extension for cold water inlet /Aquastop
WMZPW20W Platform with pull-out, washer, cubic
• : Active Water Plus For highly efficient use of water even with
smaller loads thanks to automatic load detection.
• : 4 AntiStain reliably removes common stains.
• : Reload function forgot an item? Add it easily to the wash.
• : Speed Perfect perfectly clean in up to 65% less time
• .
• : Dark Colors program ideal for gentle cleaning of dark-coloured
laundry, such as jeans.
Maximum : capacity in kg .......................................................... 9.0 kg
Built-in / Free-standing: ................................................. Free-standing
Dimensions x x of the product: .................................848 598 590 mm
Net weight: ..............................................................................73.5 kg
Connection Wrating: .................................................................. 2300
Fuse Aprotection: ...........................................................................10
Voltage: V............................................................................... 220-240
Frequency: ............................................................................ 50-60 Hz
Length electrical supply cord: .............................................. 160.0 cm
Door hinge: ...................................................................................Left
Wheels: ...........................................................................................No
EAN code: ..................................................................4242005357482
Installation typology: ..................................................... Free-standing
1 /
Series 6, washing machine, front
loader, 9 kg, 1400 rpm
WGG24409AU
Capacity
- 9 Capacity: kg
Consumption rates
- 5 Star Energy Rating
- Energy consumption 215 kWh per year based on Cottons Eco
program at 60°C, with 1400 RPM spin speed, seven times per
week. When tested in accordance with AS/NZS 2040.2. Actual
energy consumption will depend on how the appliance is used.
- 4.5 Star water rating (WELS)
- l Water consumption 78 litres per wash. Using the Cottons Eco
program at 60°C with 1400 RPM spin speed. In accordance with
AS/NZS 6400. Actual water consumption will depend on how the
appliance is used. C02278.
Programs
- Standard programs:
- Cottons: hard-wearing items made from cotton, linen or blended
fabrics Cotton Eco: energy-saving program Easy care: items made
from synthetic or blended fabrics Delicate/Silk: delicate, washable
items made from silk, viscose and synthetics Wool: hand or
machine washable items that are made from wool or contain wool
- Additional specialty programs:
- AllergyPlus/Hygienic: suits items that need to be hygienically clean
such as towels, bed sheets or pillow cases
- Drum Clean: cleaning and care program for the drum with reminder
function Dark Wash: dark coloured cottons and dark coloured easy
care fabrics Shirts/Blouses: non-iron shirts and blouses made from
cotton, linen, or blended fabrics Spin/Drain: spins and drains the
water Mixed: lightly soiled items made from cotton, linen or
blended fabrics Sportswear: sports and leisure items made from
synthetic fibres, microfibre or fleece Rinse: rinses and then spins
the the 15'/30': laundry, and then drains water Super short
program for small lightly soiled items
Performance
- ActiveWater Plus: for highly efficient use of water even with small
loads thanks to automatic load detection.
- - Spin speed 400 1400 rpm
- SpeedPerfect: perfectly clean in up to 65% less time.
- EcoSilence Drive: quiet, durable, and energy-efficient brushless
motor motor (BLDC) with 10-year warranty
Features
- 4 - Automatic stain removal system with stain options activatable
with standard programs. Simply select the type of stain on the
display and then the temperature, drum movement and soaking
time will automatically adjust to the optimal settings
- TouchControl buttons include:
- a Easy Iron: reduces creasing thanks to special spin sequence
- Rinse Plus: Adds more rinse cycles, suited for highly soiled clothing
Prewash options for stubborn stains and heavily soiled garments
Finish in (delayed start): delay the start of the program by up to 24
hours Spin Speed: manually adjust the spin speed AntiStain:
Selection options of Grass, Red Wine, Oil/Butter and Blood
Start/Pause a with Reload function: allows you to add forgotten
garment even after the wash cycle has started Temperature
selection: manually adjust the temperature SpeedPerfect: reduce
cleaning time by up to 65%
- Reload function to pause machine operation for adding in last
minute laundry items
- aDrum Clean reminder function: the LED indicator will flash when
drum clean is required
- Large LED display for program status, temperature, spin speed, and
time remaining
- soft dial
- AntiVibration Side Panels reduce vibrations and noise levels,
making it extremely quiet during the spin cycle
- Aqua Protection Plus anti-flood protection with self-sealing hose,
minimises the risk of flooding
- Foam detection system to remove excessive foam
- Unbalanced load detection
- Buzzer at the end of the programme
- Self cleaning detergent drawer to remove detergent residue, From
front
Design
- Large porthole, silver-black grey with 165° door for easy
loading/unloading
- VarioDrum: thorough yet gentle washing thanks to the unique drum
structure design
Technical Information
- Slide-under height of 85cm
- x W x x x Dimensions (H D): 84.8 cm 59.8 cm 59.0 cm (63.6 cm
including door handle)
- /Operating noise level (based on Cotton 60°C program): wash 48
75 spin dB(A)
Safety
- Child lock for door and buttons
Display & Screen Alerts
- 0 - Spin speed 1400 rpm
- Reload function to pause machine operation for adding in last
minute laundry items
- demo programme, Automatic stain removal system
- Sound insulation by additional damping material
- Sound insulation by bottom cover
- lDrum volume: 65
- Consumption Indication: Information about energy consumption
- /Operating noise level (based on Cotton 60°C program): wash 48
spin 75 dB(A)
- Noise level spinning at standard 60°C cotton programme at full
loading 1 in dB (A) re pW: 75
- l Water consumption 78 litres per wash. Using the Cottons Eco
program at 60°C with 1400 RPM spin speed. In accordance with
AS/NZS 6400. Actual water consumption will depend on how the
appliance is used. C02278.
2 /
Series 6, washing machine, front
loader, 9 kg, 1400 rpm
WGG24409AU
Series 6, washing machine, front
loader, 9 kg, 1400 rpm
WGG24409AU
3 /
Product Specifications
| Brand: | Bosch |
| Category: | Washing machine |
| Model: | WGG24409AU |
