Blaupunkt VC 2008 BLK Manual

Read below 📖 the manual in Italian for Blaupunkt VC 2008 BLK (4 pages) in the Not categorized category. This guide has been helpful for 2 people and has been rated 4.5 stars on average by 2 users

Page 1/4
VC - 2008 BLK
Car Vacuum Cleaner
Blaupunkt India Private Limited
47, Atlanta Society, Nariman Point, Mumbai‐ 400 021. India.
Toll Free: 1800 209 6820 | info@blaupunkt.in | Shop at www.blaupunktcar.in
Vacuum Cleaner
Product Prole :
The vacuum cleaner is designed for automobiles with 12V supply only. It's equipped with a high-efficiency conical
lter design that has unique rapid cleaning capability and easy replacement. No need to worry about getting
hands dirty. With the help of the vacuum cleaner, any tiny particles of dust and dry scraps in the cabin can be
removed quickly
Notice
1. Please make sure the vacuum cleaner is used in accordance with specication under normal conditions.
2. Please shut off power if not in use.
3. Suction of following articles is strictly prohibited as it will damage the cleaner & result in re or accidents.
(a) Hot objects, for example, cigarette, charcoal re, etc.
(b) Sharp fragments, for example, broken glass, etc.
(c) Corrosive, aggressive solvent or liquid.
(d) Combustible and explosive material, e.g. gasoline or alcohol products.
4. Vacuum cleaner handheld unit is a completely sealed unit and needs no lubrication. Opening the handheld
unit without permission voids warranty .
5. Do not lift the cleaner with the power cord.
6. Do not use the appliance outdoors on rainy days.
7. To extend service life of cleaner, turn off device after continuous use of 30 minutes.
8. Do not place the cleaner in water and keep it away from hot appliances or blazing sun for extended periods as
this may cause the plastic components to warp
9. Don't allow children to play with or operate the cleaner to avoid accidents.
10. Never use vacuum cleaner without a dust container or lter
11. Do not expose vacuum cleaner to water or any other liquid
12. Use only the attachments that are recommended or sold by the manufacturer
13. When disconnecting the power cable from the power source use the Plug - in Cigarette lighter adaptor plug
and do not pull on the power cord
14. Keep power cable away from sharp corners and do not attempt to use the product if power cable is damaged.
Vacuum Cleaner
General Operating Instructions:
1. Start car engine and make sure the plug - in cigarette lighter is inserted in the port.
2. Turn on the switch on the handle and get ready for use.
3. Attach appropriate suction nozzle.
4. To get better effect, suction inlet is expected to lie at on the ground while in use.
5. Turn off switch and pull out the cigarette lighter when not in use.
Operating Instructions:
When operating this device, it is recommended your vehicle engine be turned on and kept in idling position.
This will allow your vehicle battery to maintain a full charge and allow the vacuum cleaner to operate at its
maximum power and efficiency.
A. Insert the Brush Extension (2) or the Crevice Extension (1) into the Dust Container Air Inlet.
B. Insert the 12 Volt Power Plug (4) into the vehicle Power Port or Cigarette Lighter Socket.
C. Slide the Power Switch (5) to Vacuum Cleaner Power 'ON' position.
Depending on the requirements, insert the Flex Air Hose Extension (3) into the Air Inlet of the Dust Container
and then Insert the Brush Extension (2) or the Crevice Extension (1) into the Dust Container Air Inlet.
Clean Collector and Cone Filter Element:
If suction gets weak over a period of time, it is recommended to clean the see through collector and cone lter
element of the cleaner for better performance.
Message to our customers:
Before you use products, please read instruction of use carefully.
Vacuum Cleaner
Dust Collector
Receptacle
Conical Filter
Nose Cone
detach switch Power Switch
Plug-in
Cigarette
Lighter
100w Heavy
Duty Motor
1
2
3
4
5
Specification:
ŸRated Voltage: DC 12 V
ŸRated Power: 100 W
ŸPower Suction: 4.5 KPA
ŸMax Current: 8A
ŸPower Cord length: 3 meters
ŸAccessories: Flexible Hose Pipe, Brush Suction Nozzle, Long Suction Nozzle & Storage Pouch
Troubleshooting:
Failure Possible Cause
Not working
Power is turned off or cigarette
lighter plug is not plugged in correctly.
Solution
Check Power ON/OFF or make sure cigarette
lighter plug is inserted tightly.
Fuse blowout Unscrew the holder in cigarette lighter
adaptor and change fuse.
Weak suction
Thick dust in the strainer Clean dust cup and collector
Charge Battery with an external charger
Start engine
Low battery
Ergonomic
Handle

Product Specifications

Brand: Blaupunkt
Category: Not categorized
Model: VC 2008 BLK
